Immobilizer circuit for Honda Accord VI (1997-2002)

Immobilizer circuit

Get access

BLK WIRE BLK/YEL WIRE BLU WIRE BLU/ORG WIRE BRN WIRE BRN/BLK WIRE FUEL PUMP FUEL TANK UNIT FUSE 1 FUSE 13 FUSE 46 G115 (3.0L) (REAR OF ENGINE) (2.3L) G110 (LEFT FRONT OF ENGINE) GAUGE ASSEMBLY GRN WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ON OR START HOT WITH ENGINE CRANKING IMMOBILIZER INDICATOR LIGHT IMMOBILIZER RECEIVER UNIT (ON IGNITION LOCK) ORG/ WIRE PGM-FI ECU MAIN RELAY (BEHIND LEFT SIDE OF DASH, LEFT OF STEERING COLUMN) PNK IMMOB IND LT CTRL IMMOB ENABLE FUEL PUMP CTRL IMMOB CODE INPUT WIRE PNK WIRE POWER INPUT POWER INPUT GROUND RED WIRE RED/WHT WIRE WHT WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE
