Honda Accord VI (1997-2002) tdc sensor shield Wiring diagram
This page shows the only wiring diagram for the component.tdc sensor shield, which is found in the car Honda Accord VI (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tdc sensor shield (1 of 1)
A/T GEAR POSITION SWITCH
BLK WIRE
BRAIDED WIRE
BRN WIRE
COUNTERSHAFT SPEED SENSOR SHIELD
CRANKSHAFT POSITION (CKP) SENSOR SHIELD
DATA LINK CONNECTOR (DLC)
EXHAUST GAS RADIATOR RECIRCULATION FAN (EGR) VALVE SWITCH "A"
G115 (3.0L) (REAR OF ENGINE)
IDLE AIR CONTROL VALVE (IAC)
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION IGNITION COIL 6 COIL 5
IMMOBILIZER RECEIVER UNIT
MAINSHAFT SPEED SENSOR SHIELD
POWERTRAIN CONTROL MODULE (PCM)
POWERTRAIN CONTROL PGM-FI MODULE ECU MAIN (PCM) RELAY
PRIMARY
RADIATOR FAN SWITCH B
RED WIRE
SECONDARY
SHIELD
SHIFT CONTROL SOLENOID VALVE C
SHIFT CONTROL SOLENOID VALVE"B"
TDC SENSOR SHIELD
VTEC PRESSURE SWITCH
WHT WIRE
Go to component -> Ground distribution circuit (2 of 6) -> TDC SENSOR SHIELD
