Honda Accord VI (1997-2002) power window relay accessory socket relay Wiring diagram
This page shows the only wiring diagram for the component.power window relay accessory socket relay, which is found in the car Honda Accord VI (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power window relay accessory socket relay (1 of 1)
3.0L
3.0L MODELS
ABS FAIL-SAFE RELAY
BLK WIRE
BLOWER MOTOR RELAY
BLU WIRE
CANADIAN 3.0L MODELS
CANADIAN EX
CANADIAN LX, EX MODELS
CONDENSER FAN MOTOR
COUPE
COUPE W/ SIDE SRS CANADIAN EX
CRUISE CONTROL ACTUATOR
DRIVER'S VANITY MIRROR LIGHT
ELD UNIT
EX SEDAN
FRONT PASSENGER'S DOOR LOCK SWITCH
FRONT PASSENGER'S SEAT BELT SWITCH
FRONT PASSENGER'S SEAT HEATER
FRONT PASSENGER'S VANITY MIRROR LIGHT
FUEL TANK UNIT (EXCEPT COUPE)
HOOD SWITCH
LOW BEAM
LX, EX MODELS
MODEL
OPDS UNIT
PASSENGER'S MULTIPLEX CONTROL UNIT
POWER STEERING PRESSURE (PSP) SWITCH
POWER WINDOW RELAY ACCESSORY SOCKET RELAY
RADIATOR FAN MOTOR
RIGHT FRONT PARKING LIGHT
RIGHT FRONT TURN SIGNAL/ SIDE MARKER LIGHT
RIGHT HEADLIGHT
RIGHT MIRROR
RIGHT REAR DOOR LOCK KNOB SWITCH
SEAT HEATER RELAY
SPOT- LIGHTS
WASHER FLUID LEVEL SENSOR
WINDSHIELD WASHER MOTOR
Go to component -> Ground distribution circuit (5 of 6) -> POWER WINDOW RELAY ACCESSORY SOCKET RELAY
