Honda Accord VI (1997-2002) mainshaft speed sensor shield Wiring diagrams
This page contains all the electrical diagrams for the component. mainshaft speed sensor shield, in which he is found in the car Honda Accord VI (1997-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram mainshaft speed sensor shield (1 of 2)
A/T
A/T GEAR POSITION SWITCH
ABS CONTROL UNIT
ABS PUMP MOTOR
BATTERY
BLK WIRE
BRAIDED WIRE
BRAIDED WIRE BRAIDED WIRE
BRN WIRE
COUNTERSHAFT SPEED SENSOR SHIELD
CYLINDER POSITION CKP/TDC (CYP) SENSOR SENSOR SHIELD SHIELD
DATA LINK CONNECTOR (DLC)
ENGINE MOUNT BRACKET
EXHAUST GAS RECIRCULATION (EGR) VALVE
G110 (2.3L) (LEFT FRONT OF ENGINE)
G200 (2.3L) (LEFT KICK PANEL) (3.0L) G203 (RIGHT KICK PANEL)
IDLE AIR CONTROL RADIATOR (IAC) FAN VALVE SWITCH
IMMOBILIZER RECEIVER UNIT
KNOCK SENSOR (KS) SHIELD
LX, EX MODELS
M/T
MAINSHAFT SPEED SENSOR SHIELD
PGM-FI ECU MAIN RELAY
POWERTRAIN CONTROL MODULE (PCM) OR ENGINE CONTROL MODULE (ECM)
PRIMARY
RED WIRE
SECONDARY
SHIELD
SHIFT SHIFT CONTROL CONTROL SOLENOID SOLENOID VALVE "B" VALVE "C"
TRANSMISSION
VEHICLE SPEED SENSOR (VSS)
VTEC PRESSURE SWITCH
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (1 of 6) -> MAINSHAFT SPEED SENSOR SHIELD
Wiring diagram mainshaft speed sensor shield (2 of 2)
