Honda Accord VI (1997-2002) left rear window switch right rear window switch Wiring diagram
This page shows the only wiring diagram for the component.left rear window switch right rear window switch, which is found in the car Honda Accord VI (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear window switch right rear window switch (1 of 1)
BLK WIRE
BLU WIRE
CANADIAN MODELS
DAYTIME RUNNING LIGHTS (DRL) CONTROL UNIT
DIODE
DOOR MULTIPLEX CONTROL UNIT
DRIVER'S MULTIPLAY CONTROL UNIT
DX, LX MODELS EX MODEL
EX MODELS
FROM UNDERHOOD FUSE/RELAY BOX (DIAGRAM 1 OF 6)
FRONT PASSENGER'S WINDOW SWITCH
FUSE 1
FUSE 15 FUSE 8
FUSE 16 FUSE 7
FUSE 43
FUSE 44 (NOT USED)
FUSE 45
GAUGE ASSEMBLY
GRN WIRE
HEADLIGHT RELAY 1
HEADLIGHT RELAY 2
HEADLIGHTS SYSTEM
LEFT HEADLIGHT
LEFT REAR WINDOW SWITCH RIGHT REAR WINDOW SWITCH
MOON ROOF CLOSE RELAY
MOON ROOF OPEN RELAY
POWER WINDOW RELAY
RED WIRE
RED/YEL WIRE
RIGHT HEADLIGHT
US MODELS
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 6) -> LEFT REAR WINDOW SWITCH RIGHT REAR WINDOW SWITCH
