Honda Accord VI (1997-2002) left brake light/outer taillight Wiring diagrams
This page contains all the electrical diagrams for the component. left brake light/outer taillight, in which he is found in the car Honda Accord VI (1997-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left brake light/outer taillight (1 of 2)
BLK WIRE
BLU WIRE
COMBINATION LIGHT SWITCH
DRIVER'S MULTIPLEX CONTROL UNIT
DX, LX
FROM BRAKELIGHT FAILURE SENSOR (DIAGRAM 1 OF 2)
FROM DRIVER'S UNDERDASH FUSE/RELAY BOX (DIAGRAM 1 OF 2)
FROM TRAILER LIGHTING CONNECTOR (DIAGRAM 1 OF 2)
FROM TURN SIGNAL SWITCH (DIAGRAM 1 OF 2)
FUSE 10
GRN WIRE
GRN/BLU WIRE
GRN/YEL WIRE
HEAD PARK
HEADLIGHT SWITCH
HOT AT ALL TIMES
LEFT BRAKE LIGHT/OUTER TAILLIGHT
LEFT FRONT PARKING LIGHT
LEFT FRONT TURN SIGNAL, SIDE MARKER LIGHT
LEFT INNER TAILLIGHT
LICENSE PLATE LIGHT
OFF
OFF HEAD PARK
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT BRAKE LIGHT/OUTER TAILLIGHT
RIGHT FRONT PARKING LIGHT
RIGHT FRONT TURN SIGNAL/ SIDE MARKER LIGHT
RIGHT INNER TAILLIGHT
SECURITY SYSTEM CONNECTOR (OPTION)
TAILLIGHT RELAY (BEHIND RIGHT KICK PANEL)
TAILLIGHT RELAY CONTROL
YEL WIRE
Go to component -> Exterior lamps circuit, sedan (2 of 2) -> LEFT BRAKE LIGHT/OUTER TAILLIGHT
Wiring diagram left brake light/outer taillight (2 of 2)
BLK WIRE
BLU WIRE
BRAKELIGHT FAILURE SENSOR
COUPE
DX, LX MODELS
EX MODELS
LATCH SWITCH
LATCH SWITCH OPENER MOTOR TRUNK KEY CYLINDER SWITCH
LEFT BACK-UP LIGHT
LEFT BRAKE LIGHT/OUTER TAILLIGHT
LEFT INNER BRAKE- LIGHT/ TAILLIGHT
LEFT INNER TAILLIGHT
LEFT REAR SIDE MARKER LIGHT
LEFT REAR TURN SIGNAL LIGHT
LEFT TAILLIGHT ASSEMBLY
LICENSE PLATE LIGHT
NCA WIRE
OPENER MOTOR
OUTER BRAKE LIGHT/ TAILLIGHT
RIGHT BACK-UP LIGHT
RIGHT BRAKE LIGHT/OUTER TAILLIGHT
RIGHT INNER BRAKE LIGHT/ TAILLIGHT
RIGHT INNER TAILLIGHT
RIGHT REAR SIDE MARKER LIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT TAILLIGHT ASSEMBLY
SEDAN
TRAILER LIGHTING CONNECTOR
TRUNK KEY CYLINDER SWITCH
TRUNK LATCH
TRUNK LATCH SWITCH
TRUNK LID LATCH
TURN SIGNAL LIGHT/ TAILLIGHT
WHT WIRE
Go to component -> Ground distribution circuit (6 of 6) -> LEFT BRAKE LIGHT/OUTER TAILLIGHT
