Honda Accord VI (1997-2002) htr fan sw input illumination - wiring diagram
This page shows the only wiring diagram for the component.htr fan sw input illumination -, which is found in the car Honda Accord VI (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
htr fan sw input illumination - wiring diagram (1 of 1)
AIR MIX CONTROL MOTOR (BELOW DASH, ON RIGHT SIDE OF HEATER UNIT)
AMD-P
BLK WIRE
BLK/YEL WIRE
BLOWER MOTOR (BEHIND RIGHT SIDE OF DASH, IN BLOWER HOUSING)
BLOWER MOTOR RELAY
BLOWER RESISTOR (AT BLOWER MOTOR)
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
FRS
FUSE 13
FUSE 56
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
HEATER CONTROL PANEL
HEATER FAN SWITCH
HOT AT ALL TIMES
HOT IN ON FUSE 3
HTR FAN SW INPUT ILLUMINATION -
LT GRN/BLK WIRE
M-COOL
M-DEF
M-HOT
M-VENT
MODE 1
MODE 2
MODE 3
MODE 4
MODE CONTROL MOTOR (ON LEFT SIDE OF HEATER UNIT)
OFF
PNK/BLK WIRE
REC
RECIRCULATION CONTROL MOTOR (BEHIND GLOVE BOX, ON BLOWER UNIT)
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
S-COM
WHT/YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
