Honda Accord VI (1997-2002) hot in on or Wiring diagram
This page shows the only wiring diagram for the component.hot in on or, which is found in the car Honda Accord VI (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot in on or (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
DRIVER'S DOOR SWITCH
DRIVER'S MULTIPLEX CONTROL UNIT
DRIVER'S UNDERDASH FUSE/RELAY BOX (BEHIND RIGHT SIDE OF DASH)
FRONT PASSENGER'S WINDOW MOTOR
FRONT PASSENGER'S WINDOW SWITCH O = OFF 1 = DOWN 2 = UP
FUSE 13
FUSE 9
GRN WIRE
GRN/BLU WIRE
HOT AT ALL TIMES
HOT IN ON OR
LEFT REAR WINDOW MOTOR
LEFT REAR WINDOW SWITCH O = OFF 1 = DOWN 2 = UP
ORG/ WIRE
PASSENGER'S UNDERDASH FUSE/RELAY BOX
PASSENGER'S UNDERDASH FUSE/RELAY BOX (BEHIND RIGHT SIDE OF DASH)
PNK WIRE
RED WIRE
RED) (OR WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT REAR WINDOW
RIGHT REAR WINDOW SWITCH O = OFF 1 = DOWN 2 = UP
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL (OR WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Power window circuit (2 of 2) -> HOT IN ON OR
