Honda Accord VI (1997-2002) hot at all times pass- enger's under- dash fuse/ relay box fuse 13 Wiring diagram

3 (DX 2) 3.0L A/T GEAR POSITION INDICATOR DIMMING CIRCUIT ANTI-LOCK BRAKES SYSTEM ATP 2 ATP 1 NCSG ATP NP LSA + LSB - BLK WIRE BLK/BLU WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRAIDED WIRES (2.3L) BRAIDED WIRES (3.0L) BRAKE SWITCH (ON BRAKE PEDAL SUPPORT) BRN WIRE BRN/BLK (OR BLK) WIRE BRN/BLK WIRE COUNTERSHAFT SPEED SENSOR (2.3L: TOP LEFT 3.OL: TOP RIGHT OF TRANSAXLE) CRUSIE CONTROL CRS VSS OUT SCS DATA LINK CONNECTOR (LOWER LEFT SIDE OF DASH, ABOVE KICK PANEL) DK BLU WIRE DRIVER'S MULTIPLEX CONTROL UNIT DRIVER'S MULTIPLEX CONTROL UNIT (BEHIND LEFT FUSE BOX COVER) DRIVER'S UNDER DASH FUSE /RELAY CENTER DRIVER'S UNDER- DASH FUSE/ RELAY BOX DRIVER'S UNDERDASH DASH FUSE/ RELAY BOX ENGINE CONTROLS SYSTEM ENGINE CONTROLS SYSTEM (VEHICLE SPEED SENSOR) ENGINE CONTROLS SYSTEM LOCK-UP CONTROL SOLENOID VALVE FUSE 46 FUSE 9 GAUGE ASSEMBLY GRN WIRE GRN/BLK WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT AT ALL TIMES PASS- ENGER'S UNDER- DASH FUSE/ RELAY BOX FUSE 13 HOT AT ALL TIMES UNDER- HOOD FUSE/ RELAY BOX FUSE 47 HOT IN ON OR START HOT IN ON OR START DRIVER'S UNDER- DASH FUSE/ RELAY BOX FUSE 1 LC SH B SH C ATP R SH A LSA - LSB MAINSHAFT SPEED SENSOR (2.3L: RIGHT REAR, 3.0L: LEFT REAR OF TRANSAXLE) NC NM NMSG ORG/ WIRE PGM-FI ECU MAIN RELAY (BEHIND LEFT SIDE OF DASH, LEFT OF STEERING COLUMN) PNK WIRE POWERTRAIN CONTROL MODULE (BEHIND CENTER OF DASH, FORWARD OF FLOOR CONSOLE) PRESSURE SWITCH (2.3L: LEFT FRONT, 3.0L: RIGHT FRONT OF TRANSAXLE) PRESSURE SWITCH (2.3L: RIGHT REAR 3.0L: LEFT REAR OF TRANSAXLE) RED WIRE RED/BLK WIRE RED/WHT WIRE REVERSE RELAY SHIFT CONTROL SOLENOID VALVES (2.3L RIGHT SIDE, 3.OL: LEFT SIDE OF TRANSAXLE) SLU BKSW STARTING/ CHARGING SYSTEM THROTTLE POSITION SENSOR (ON THROTTLE BODY) TPS ECT VBU WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE
