Honda Accord VI (1997-2002) headlight switch Wiring diagrams
This page contains all the electrical diagrams for the component. headlight switch, in which he is found in the car Honda Accord VI (1997-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram headlight switch (1 of 6)
1 OF 2)
BLK WIRE
BLU WIRE
COMBINATION LIGHT SWITCH
DRIVER'S MULTIPLEX CONTROL UNIT
DX, LX
FROM BRAKELIGHT FAILURE SENSOR (DIAGRAM 1 OF 2)
FROM DRIVER'S UNDERDASH FUSE/RELAY BOX (DIAGRAM
FROM DRIVER'S UNDERDASH FUSE/RELAY BOX (DIAGRAM 1 OF 2)
FROM TRAILER LIGHTING CONNECTOR (DIAGRAM 1 OF 2)
FROM TURN SIGNAL SWITCH (DIAGRAM 1 OF 2)
FUSE 10
GRN WIRE
GRN/BLU WIRE
GRN/YEL WIRE
HEADLIGHT SWITCH
HOT AT ALL TIMES
LEFT FRONT PARKING LIGHT
LEFT FRONT TURN SIGNAL, SIDE MARKER LIGHT
LEFT INNER BRAKE- LIGHT/ TAILLIGHT
LEFT REAR SIDE MARKER LIGHT
LICENSE PLATE LIGHT
OFF HEAD PARK
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT PARKING LIGHT
RIGHT FRONT TURN SIGNAL/ SIDE MARKER LIGHT
RIGHT INNER BRAKE LIGHT/ TAILLIGHT
RIGHT REAR SIDE MARKER LIGHT
SECURITY SYSTEM CONNECTOR (OPTION)
TAILLIGHT RELAY (BEHIND RIGHT KICK PANEL)
TAILLIGHT RELAY CONTROL
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, coupe (2 of 2) -> HEADLIGHT SWITCH
Wiring diagram headlight switch (2 of 6)
BLK WIRE
BLU WIRE
COMBINATION LIGHT SWITCH
DRIVER'S MULTIPLEX CONTROL UNIT
DX, LX
FROM BRAKELIGHT FAILURE SENSOR (DIAGRAM 1 OF 2)
FROM DRIVER'S UNDERDASH FUSE/RELAY BOX (DIAGRAM 1 OF 2)
FROM TRAILER LIGHTING CONNECTOR (DIAGRAM 1 OF 2)
FROM TURN SIGNAL SWITCH (DIAGRAM 1 OF 2)
FUSE 10
GRN WIRE
GRN/BLU WIRE
GRN/YEL WIRE
HEAD PARK
HEADLIGHT SWITCH
HOT AT ALL TIMES
LEFT BRAKE LIGHT/OUTER TAILLIGHT
LEFT FRONT PARKING LIGHT
LEFT FRONT TURN SIGNAL, SIDE MARKER LIGHT
LEFT INNER TAILLIGHT
LICENSE PLATE LIGHT
OFF
OFF HEAD PARK
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT BRAKE LIGHT/OUTER TAILLIGHT
RIGHT FRONT PARKING LIGHT
RIGHT FRONT TURN SIGNAL/ SIDE MARKER LIGHT
RIGHT INNER TAILLIGHT
SECURITY SYSTEM CONNECTOR (OPTION)
TAILLIGHT RELAY (BEHIND RIGHT KICK PANEL)
TAILLIGHT RELAY CONTROL
YEL WIRE
Go to component -> Exterior lamps circuit, sedan (2 of 2) -> HEADLIGHT SWITCH
Wiring diagram headlight switch (3 of 6)
BATTERY INPUT
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
COMBINATION LIGHT SWITCH
DIMMER SWITCH
DIODE
DRIVER'S MULTIPLEX CONTROL UNIT
DRIVER'S MULTIPLEX CONTROL UNIT (EX) (BEHIND LEFT FUSE BOX COVER)
DRIVER'S UNDERDASH FUSE/RELAY BOX
DRIVER'S UNDERDASH FUSE/RELAY BOX (EX)
DRL CONTROL UNIT (BEHIND LEFT SIDE OF DASH)
DRL IND LIGHT
DX, LX
ELD UNIT
EX+
FLASH TO PASS SWITCH
FUSE 41
FUSE 43
FUSE 44
FUSE 45
FUSE 5
FUSE 6 10 A
FUSE 9
GAUGE ASSEMBLY
GRN WIRE
GRN/WHT WIRE
GROUND
HEAD OFF PARK
HEADLIGHT RELAY 1
HEADLIGHT RELAY 2
HEADLIGHT SWITCH
HIGH BEAM CUT RELAY (BEHIND RIGHT KICK PANEL)
HIGH BEAM INDICATOR LIGHT
HIGH BEAM REQUEST
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
IGNITION ON INPUT
INDICATOR LIGHT CONTROL
INSTRUMENT CLUSTER SYSTEM (BRAKE SYSTEM INDICATOR LIGHT) BRAKE INDICATOR OUTPUT
LEFT HEADLIGHT
LEFT HIGH BEAM CONTROL
LEFT LOW BEAM INPUT
LIGHTS ON REQUEST INPUT
LO HI
NOT USED NOT USED
ORG/ WIRE
ORG/WHT WIRE
PARKING BRAKE INPUT
PARKING BRAKE SWITCH
PASSENGER'S MULTIPLEX CONTROL UNIT
PASSENGER'S UNDERDASH FUSE/RELAY BOX
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT HEADLIGHT
RIGHT HIGH BEAM CONTROL
RIGHT LOW BEAM INPUT
TO FOG- LIGHT DIODE (DIAGRAM 2 OF 2)
UNDERHOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Headlight circuit, with drl (1 of 2) -> HEADLIGHT SWITCH
Wiring diagram headlight switch (4 of 6)
BATTERY
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
COMBI- NATION LIGHT SWITCH
COMBINATION LIGHT SWITCH
DRIVER'S UNDERDASH FUSE/RELAY BOX
FOG LIGHT SWITCH
FOGLIGHT DIODE (BEHIND DRIVER'S DASH LOWER COVER)
FOGLIGHT IN-LINE FUSE (ATTACHED TO BATTERY BRACKET)
FOGLIGHT RELAY 1 (BEHIND LEFT KICK PANEL)
FOGLIGHT RELAY 2 (ATTACHED TO BATTERY BRACKET)
FROM DRIVER'S UNDERDASH FUSE/RELAY BOX (DIAGRAM 1 OF 2)
GRN WIRE
HEAD LIGHT SWITCH
HEADLIGHT SWITCH
HOT AT ALL TIMES FUSE 10
ILL
LEFT FOGLIGHT
OFF
OFF HEAD PARK
ON IND.
ORG/ WIRE
ORG/WHT WIRE
PASSENGER'S UNDERDASH FUSE/RELAY BOX
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RIGHT FOGLIGHT
WHT WIRE
YEL WIRE
Go to component -> Headlight circuit, with drl (2 of 2) -> HEADLIGHT SWITCH
Wiring diagram headlight switch (5 of 6)
BATTERY
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
COMBI- NATION LIGHT SWITCH
COMBINATION LIGHT SWITCH
DIMMER SWITCH
DOOR MULTIPLEX CONTROL UNIT
DRIVER'S DOOR LOCK KNOB SWITCH
DRIVER'S DOOR SWITCH
DRIVER'S MULTIPLEX CONTROL UNIT
DRIVER'S MULTIPLEX CONTROL UNIT (BEHIND LEFT FUSE BOX COVER)
DRIVER'S UNDERDASH FUSE/RELAY BOX
ELD UNIT
FLASH TO PASS SWITCH
FOG LIGHT SWITCH
FOGLIGHT DIODE (BEHIND DRIVER'S DASH LOWER COVER)
FOGLIGHT IN-LINE FUSE (ATTACHED TO BATTERY BRACKET)
FOGLIGHT RELAY 1 (BEHIND LEFT KICK PANEL)
FOGLIGHT RELAY 2 (ATTACHED TO BATTERY BRACKET)
FUSE 41
FUSE 43
FUSE 44
FUSE 45
GAUGE ASSEMBLY
GRN WIRE
GRN/ORG WIRE
HEAD LIGHT SWITCH
HEAD OFF PARK
HEADLIGHT RELAY 1
HEADLIGHT RELAY 2
HEADLIGHT SWITCH
HIGH BEAM IND
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE 10
IGNITION KEY SWITCH
ILL
LEFT HEADLIGHT (HIGH)
LO ON ON HI
OFF
OFF HEAD PARK
ON IND.
ORG/ WIRE
ORG/WHT WIRE
PASSENGER'S MULTIPLEX CONTROL UNIT
PASSENGER'S UNDERDASH FUSE/RELAY BOX
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FOG LIGHT LEFT FOG LIGHT
RIGHT HEADLIGHT LOW HIGH
STEERING LOCK
UNDERHOOD FUSE/RELAY BOX (RIGHT REAR CORNER OF ENG COMPT)
WHT WIRE
YEL WIRE
Go to component -> Headlight circuit, without drl & with auto-off headlamps -> HEADLIGHT SWITCH
Wiring diagram headlight switch (6 of 6)
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
COMBI- NATION LIGHT SWITCH
COMBINATION LIGHT SWITCH
DIMMER SWITCH
DRIVER'S UNDERDASH FUSE/RELAY BOX
ELD UNIT
FLASH TO PASS SWITCH
FOG LIGHT SWITCH
FOGLIGHT DIODE (BEHIND DRIVER'S DASH LOWER COVER)
FOGLIGHT IN-LINE FUSE (ATTACHED TO BATTERY BRACKET)
FOGLIGHT RELAY 1 (BEHIND LEFT KICK PANEL)
FOGLIGHT RELAY 2 (ATTACHED TO BATTERY BRACKET)
FUSE 41
FUSE 43
FUSE 44
FUSE 45
GAUGE ASSEMBLY
GRN WIRE
HEAD LIGHT SWITCH
HEAD OFF PARK BATTERY
HEADLIGHT RELAY 1
HEADLIGHT RELAY 2
HEADLIGHT SWITCH
HIGH BEAM IND
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE 10
ILL
LEFT HEADLIGHT (HIGH)
LO ON ON HI
OFF
OFF HEAD PARK
ON IND.
ORG/ WIRE
ORG/WHT WIRE
PASSENGER'S MULTIPLEX CONTROL UNIT
PASSENGER'S UNDERDASH FUSE/RELAY BOX
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FOG LIGHT LEFT FOG LIGHT
RIGHT HEADLIGHT (HIGH)
UNDERHOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Headlight circuit, without drl & without auto-off headlamps -> HEADLIGHT SWITCH
