Honda Accord VI (1997-2002) front pass- enger's door switch Wiring diagram
This page shows the only wiring diagram for the component.front pass- enger's door switch, which is found in the car Honda Accord VI (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front pass- enger's door switch (1 of 1)
ANTI-THEFT SYSTEM
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
CEILING LIGHT
DRIVER'S DOOR COURTESY LIGHT
DRIVER'S DOOR SWITCH
DRIVER'S DOOR SWITCH LEFT REAR DOOR SWITCH
DRIVER'S UNDERDASH FUSE/RELAY BOX
DX, LX
DX, LX MODELS ONLY
FRONT PASS- ENGER'S DOOR SWITCH
FRONT PASSENGER'S DOOR COURTESY LIGHT
FRONT PASSENGER'S DOOR SWITCH
FUSE 11
GAUGE ASSEMBLY
GRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
IN-LINE DIODE 1
IN-LINE DIODE 2
IN-LINE DIODE 3
IN-LINE DIODE 4
LATCH SWITCH
LEFT
LEFT REAR DOOR COURTESY LIGHT (SEDAN)
LEFT REAR DOOR SWITCH (SEDAN)
ON OFF DOOR
ON OFF OFF
ORG/ WIRE
PASSENGER'S MULTIPLEX CONTROL UNIT (NOT USED)
PASSENGER'S UNDERDASH FUSE/RELAY BOX
RIGHT
RIGHT REAR DOOR COURTESY LIGHT (SEDAN)
RIGHT REAR DOOR SWITCH
RIGHT REAR DOOR SWITCH (SEDAN)
SAFETY INDICATOR CIRCUIT
SEDAN ONLY
SPOTLIGHTS
TRUNK LATCH
TRUNK LATCH SWITCH
TRUNK LIGHT
WHT/BLU WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/WHT WIRE
Go to component -> Courtesy lamps circuit -> FRONT PASS- ENGER'S DOOR SWITCH
