Honda Accord VI (1997-2002) countershaft speed sensor shield Wiring diagrams
This page contains all the electrical diagrams for the component. countershaft speed sensor shield, in which he is found in the car Honda Accord VI (1997-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
countershaft speed sensor shield wiring diagram (1 of 2)
A/T
A/T GEAR POSITION SWITCH
ABS CONTROL UNIT
ABS PUMP MOTOR
BATTERY
BLK WIRE
BRAIDED WIRE
BRAIDED WIRE BRAIDED WIRE
BRN WIRE
COUNTERSHAFT SPEED SENSOR SHIELD
CYLINDER POSITION CKP/TDC (CYP) SENSOR SENSOR SHIELD SHIELD
DATA LINK CONNECTOR (DLC)
ENGINE MOUNT BRACKET
EXHAUST GAS RECIRCULATION (EGR) VALVE
G110 (2.3L) (LEFT FRONT OF ENGINE)
G200 (2.3L) (LEFT KICK PANEL) (3.0L) G203 (RIGHT KICK PANEL)
IDLE AIR CONTROL RADIATOR (IAC) FAN VALVE SWITCH
IMMOBILIZER RECEIVER UNIT
KNOCK SENSOR (KS) SHIELD
LX, EX MODELS
M/T
MAINSHAFT SPEED SENSOR SHIELD
PGM-FI ECU MAIN RELAY
POWERTRAIN CONTROL MODULE (PCM) OR ENGINE CONTROL MODULE (ECM)
PRIMARY
RED WIRE
SECONDARY
SHIELD
SHIFT SHIFT CONTROL CONTROL SOLENOID SOLENOID VALVE "B" VALVE "C"
TRANSMISSION
VEHICLE SPEED SENSOR (VSS)
VTEC PRESSURE SWITCH
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (1 of 6) -> COUNTERSHAFT SPEED SENSOR SHIELD
countershaft speed sensor shield wiring diagram (2 of 2)
A/T GEAR POSITION SWITCH
BLK WIRE
BRAIDED WIRE
BRN WIRE
COUNTERSHAFT SPEED SENSOR SHIELD
CRANKSHAFT POSITION (CKP) SENSOR SHIELD
DATA LINK CONNECTOR (DLC)
EXHAUST GAS RADIATOR RECIRCULATION FAN (EGR) VALVE SWITCH "A"
G115 (3.0L) (REAR OF ENGINE)
IDLE AIR CONTROL VALVE (IAC)
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION IGNITION COIL 6 COIL 5
IMMOBILIZER RECEIVER UNIT
MAINSHAFT SPEED SENSOR SHIELD
POWERTRAIN CONTROL MODULE (PCM)
POWERTRAIN CONTROL PGM-FI MODULE ECU MAIN (PCM) RELAY
PRIMARY
RADIATOR FAN SWITCH B
RED WIRE
SECONDARY
SHIELD
SHIFT CONTROL SOLENOID VALVE C
SHIFT CONTROL SOLENOID VALVE"B"
TDC SENSOR SHIELD
VTEC PRESSURE SWITCH
WHT WIRE
Go to component -> Ground distribution circuit (2 of 6) -> COUNTERSHAFT SPEED SENSOR SHIELD
