Honda Accord VI (1997-2002) climate control unit heater control panel wiring diagram
This page shows the only wiring diagram for the component.climate control unit heater control panel, which is found in the car Honda Accord VI (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
climate control unit heater control panel wiring diagram (1 of 1)
1 2 3 4 5 6 7 8 RLY CTRL IGN ON RLY CTRL GROUND FAN SW B BATT IN IGN ON FAN SW A
A/C PRESSURE SWITCH (BEHIND RIGHT SIDE FRONT BUMPER) LO HI
AUTO A/C MANUAL A/C
BLK WIRE
BLK/YEL WIRE
BLU WIRE
CLIMATE CONTROL UNIT HEATER CONTROL PANEL
CONDENSER FAN RELAY
DRIVER'S UNDERDASH FUSE/RELAY BOX FUSE 6
FUSE 57 FUSE 58
GRN WIRE
HOT AT ALL TIMES
HOT IN ON FUSE 3
HOT IN ON OR START
PASSENGER'S UNDERDASH FUSE/RELAY BOX (NOT USED)
POWERTRAIN CONTROL MODULE (FORWARD OF FLOOR CONSOLE)
RADIATOR FAN CONTROL MODULE (BEHIND GLOVE BOX)
RADIATOR FAN MOTOR CONDENSER FAN MOTOR
RADIATOR FAN RELAY
RADIATOR FAN SWITCH A (ON THERMOSTAT COVER)
RADIATOR FAN SWITCH B (ON FRONT OF LEFT CYLINDER HEAD)
RED WIRE
UNDERHOOD FUSE/RELAY BOX
WHT WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
YEL/WHT WIRE
Go to component -> 3.0l, cooling fan circuit -> CLIMATE CONTROL UNIT HEATER CONTROL PANEL
