Honda Accord VI (1997-2002) cigarette lighter in-line fuse Wiring diagram
This page shows the only wiring diagram for the component.cigarette lighter in-line fuse, which is found in the car Honda Accord VI (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cigarette lighter in-line fuse (1 of 1)
1 3 (EXCEPT DX) (DX)
3.0L
A/T REVERSE RELAY
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRAKELIGHT FAILURE SENSOR
CANADIAN MODELS
CIGARETTE LIGHTER
CIGARETTE LIGHTER IN-LINE FUSE
CIGARETTE LIGHTER RELAY
CLOCK
COIL
CONTACTS COIL
DISTRIBUTOR
DRIVER'S MULTIPLEX CONTROL UNIT
FROM DRIVER'S UNDERDASH FUSE/RELAY BOX (DIAGRAM 1 OF 6)
FROM DRIVER'S UNDERDASH FUSE/RELAY BOX (DIAGRAM 4 OF 6)
FROM DRIVER'S UNDERDASH FUSE/RELAY BOX (DIAGRAM 5 OF 6)
FROM IGNITION SWITCH (DIAGRAM 4 OF 6)
FRONT ASHTRAY
FUSE 1
FUSE 10
FUSE 11
FUSE 12
FUSE 2
FUSE 7
FUSE 9
GAUGE ASSEMBLY
GRN WIRE
HAZARD WARNING SWITCH
IGNITION COIL 2 IGNITION COIL 1
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
LX, EX MODELS
M/T A/T
OPDS UNIT
PASSENGER'S MULTIPLEX CONTROL UNIT
PASSENGER'S UNDERDASH FUSE/RELAY BOX
PGM-FI ECU MAIN RELAY
RED WIRE
RED/BLU WIRE
SECURITY SYSTEM CONNECTOR (OPTION)
SHIFT LOCK SOLENOID BACK-UP LIGHT SWITCH
SRS CONTROL UNIT
TO DRIVER'S UNDERDASH FUSE/RELAY BOX (DIAGRAM 5 OF 6)
TO DRIVER'S UNDERDASH FUSE/RELAY BOX (DIAGRAM 6 OF 6)
US MODELS EXCEPT EX
W/ SIDE SRS
WHT WIRE
WHT/RED WIRE
WINDSHIELD WIPER INTERMITTENT RELAY
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER/ WASHER SWITCH
YEL WIRE
YEL/GRN WIRE
Go to component -> Power distribution circuit (5 of 6) -> CIGARETTE LIGHTER IN-LINE FUSE
