Honda Accord VI (1997-2002) brake light input ground safety ind output ignition brake switch input Wiring diagram
This page shows the only wiring diagram for the component.brake light input ground safety ind output ignition brake switch input, which is found in the car Honda Accord VI (1997-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram brake light input ground safety ind output ignition brake switch input (1 of 1)
3.0L
ANTI-LOCK BRAKES SYSTEM
BACK-UP LIGHTS CIRCUIT
BLK WIRE
BLU WIRE
BRAKE LIGHT INPUT GROUND SAFETY IND OUTPUT IGNITION BRAKE SWITCH INPUT
BRAKE SWITCH (ON BRAKE PEDAL SUPPORT)
BRAKELIGHT FAILURE SENSOR (ON LEFT REAR TAILLIGHT ASSEMBLY)
COMBINATION LIGHT SWITCH
EXCEPT DX DX
FUSE 10
FUSE 49
FUSE 9
GAUGE ASSEMBLY
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HAZARD WARNING SWITCH
HAZARD WARNING SWITCH LIGHT
HIGH MOUNT BRAKE LIGHT
HOT AT ALL TIMES
HOT IN ON OR START
LEFT
LEFT REAR TURN SIGNAL LIGHT
LEFT TURN SIGNAL INDICATOR
OFF
RED WIRE
RED/BLK WIRE
RIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT TURN SIGNAL INDICATOR
SAFETY INDICATOR
TO BRAKE- LIGHTS (DIAGRAM 2 OF 2)
TO FRONT TURN/SIGNAL SIDE MARKER LIGHTS (DIAGRAM 2 OF 2)
TRAILER LIGHTING CONNECTOR (LEFT REAR SIDE OF TRUNK, NEAR TAILLIGHT ASSEMBLY)
TURN SIGNAL SWITCH
TURN SIGNAL/ HAZARD RELAY
W/O OPTIONAL REAR SPOILER
W/OPTIONAL REAR SPOILER
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Exterior lamps circuit, sedan (1 of 2) -> BRAKE LIGHT INPUT GROUND SAFETY IND OUTPUT IGNITION BRAKE SWITCH INPUT
