Power door lock circuit, without keyless entry for Honda Accord V (1993-1998)
Power door lock circuit, without keyless entry
BATTERY INPUT
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
CANADA
DRIVER'S DOOR LOCK ACTUATOR
DRIVER'S DOOR LOCK KEY CYLINDER SWITCH
DRIVER'S DOOR LOCK SWITCH
HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX FUSE 38
LEFT REAR DOOR LOCK ACTUATOR
LOCK
LOCK UNLOCK
ORG/ WIRE
PNK 1 2 3 4 5 6 7 8 9 10 11 12 13 14 LOCK INPUT UNLOCK INPUT WIRE
PNK WIRE
POWER DOOR LOCK CONTROL UNIT (INSIDE DRIVER'S DOOR)
RIGHT FRONT DOOR LOCK ACTUATOR
RIGHT FRONT DOOR LOCK KEY CYLINDER SWITCH
RIGHT FRONT DOOR LOCK SWITCH
RIGHT REAR DOOR LOCK ACTUATOR
SECURITY SYSTEM CONNECTOR (OPTION) (LEFT KICK PANEL)
UNLOCK
UNLOCK INPUT
UNLOCK/LOCK OUTPUT GROUND UNLOCK/LOCK OUTPUT UNLOCK INPUT LOCK INPUT
WHT WIRE
WHT/RED WIRE
YEL/RED WIRE
