Power door lock circuit, with keyless entry for Honda Accord V (1993-1998)
Power door lock circuit, with keyless entry
2 1 4 3 SECURITY SYSTEM CONNECTOR (OPTION) (LEFT KICK PANEL)
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
DRIVER'S DOOR LOCK ACTUATOR
DRIVER'S DOOR LOCK KEY CYLINDER SWITCH
DRIVER'S DOOR LOCK SWITCH
HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX FUSE 38
IGNITION KEY SWITCH (STEERING LOCK ASSEMBLY)
IN-LINE DIODE A (BEHIND LEFT I/P)
IN-LINE DIODE B (RIGHT REAR OF ROOF)
INSTRUMENT CLUSTERS SYSTEM
INTERIOR LIGHTS SYSTEM (GAUGE ASSEMBLY)
KEYLESS ENTRY CONTROL MODULE (BELOW DRIVER'S SEAT)
LEFT REAR DOOR LOCK ACTUATOR
LOCK
LT BLU WIRE
ORG/ WIRE
PNK WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT FRONT DOOR LOCK ACTUATOR
RIGHT FRONT DOOR LOCK KEY CYLINDER SWITCH
RIGHT FRONT DOOR LOCK SWITCH
RIGHT REAR DOOR LOCK ACTUATOR
TAILGATE DOOR LOCK ACTUATOR (LATCH ASSEMBLY)
TAILGATE DOOR LOCK KEY CYLINDER SWITCH (RIGHT SIDE OF TAILGATE)
UNLOCK
UNLOCK/LOCK OUTPUT UNLOCK/LOCK OUTPUT
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/RED WIRE
