Instrument illumination circuit for Honda Accord V (1993-1998)
Instrument illumination circuit
8 BULBS
A/T GEAR POSITION CONSOLE LIGHT
A/T GEAR POSITION INDICATOR
ANTI-THEFT SYSTEM (OPTIONAL)
ASHTRAY LIGHT
BLK WIRE
CIGARETTE LIGHTER
CLOCK
COMBINATION LIGHT SWITCH
CRUISE CONTROL MAIN SWITCH
DASH LIGHTS BRIGHTNESS CONTROLLER (BEHIND LEFT SIDE OF I/P)
DIM SIGNAL INPUT
DIMMER
DIMMING CIRCUIT
DRIVER'S VANITY MIRROR LIGHT (OPTIONAL)
GAUGE ASSEMBLY
GAUGE ASSEMBLY LIGHTS
GLOVE BOX LIGHT
GRY WIRE
HAZARD WARNING SWITCH
HEAD OFF PARK
HEADLIGHT SWITCH
HEATER CONTROL PANEL
HOT AT ALL TIMES
J/C
LIGHTER ILLUM.
MOONROOF SWITCH
OFF
PASSENGER'S VANITY MIRROR LIGHT (OPTIONAL)
REAR WINDOW DEFOGGER SWITCH
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
SMALL LIGHT FUSE 32
STEREO RADIO/ CASSETTE PLAYER
UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL)
UNDER-HOOD FUSE/RELAY BOX
