Ignition key light circuit for Honda Accord V (1993-1998)
Ignition key light circuit
BATTERY INPUT
BLK WIRE
DOOR SWITCH INPUT
DRIVER'S DOOR SWITCH
ENTRY LIGHT TIMER (INTEGRATED CONTROL UNIT)
GRN/ORG WIRE
GROUND
HOT AT ALL TIMES
IGN KEY LIGHT CTRL
IGNITION KEY LIGHT STEERING LOCK ASSEMBLY
INTERIOR LIGHT FUSE 37
STOP LIGHT, HORN FUSE 30
UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL)
UNDER-HOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPARTMENT)
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/YEL WIRE
