Courtesy lamps circuit, wagon for Honda Accord V (1993-1998)
Courtesy lamps circuit, wagon
ANTI-THEFT SYSTEM (OPTIONAL)
BLK WIRE
BLK/WHT LT BLU OR WIRE
BLK/WHT WIRE
CARGO LIGHT
CEILING LIGHT
DRIVER'S DOOR COURTESY LIGHT
DRIVER'S DOOR SWITCH
GAUGE ASSEMBLY
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
IN-LINE DIODE A (BEHIND LEFT I/P)
IN-LINE DIODE B (RIGHT REAR OF ROOF)
INSTRUMENT CLUSTER SYSTEM
INTERIOR LIGHT FUSE 37
J/C
KEYLESS ENTRY SYSTEM (OPTIONAL)
LEFT REAR DOOR COURTESY LIGHT
LEFT REAR DOOR SWITCH
LT BLU WIRE
LX WAGON
OFF
ON OFF
ORG/ WIRE
RIGHT FRONT DOOR COURTESY LIGHT
RIGHT FRONT DOOR SWITCH
RIGHT REAR DOOR COURTESY LIGHT
RIGHT REAR DOOR SWITCH
SPOT LIGHTS (OPTIONAL)
TAILGATE LATCH SWITCH (LATCH ASSEMBLY)
UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL)
UNDER-HOOD FUSE/RELAY BOX
WHT/BLU WIRE
