Honda Accord V (1993-1998) Exterior light circuit, coupe & sedan
Exterior light circuit, coupe & sedan (1 of 2)
BLK WIRE
BRAKE LIGHT FAILURE SENSOR (BEHIND LEFT TAILLIGHT)
BRAKE LIGHT SWITCH (LEFT SIDE OF I/P)
COMBINATION LIGHT SWITCH
FUSE 30
GRN WIRE
GRN/BLU WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HEADLIGHT SWITCH HEAD OFF PARK
HIGH MOUNT BRAKE LIGHT
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
LEFT BACK-UP LIGHT
LEFT BRAKE LIGHT/ TAILLIGHT
LEFT FRONT FENDER)
LEFT FRONT PARKING LIGHT
LEFT FRONT SIDE MARKER
LEFT FRONT TURN SIGNAL
LEFT LICENSE LIGHT
LEFT REAR SIDE MARKER LIGHT
LEFT REAR TURN SIGNAL LIGHT
ORG/ WIRE
RED/BLK WIRE
RED/GRN WIRE
RIGHT BACK-UP LIGHT
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT FRONT PARKING LIGHT
RIGHT FRONT SIDE MARKER
RIGHT FRONT TURN SIGNAL
RIGHT LICENSE LIGHT
RIGHT REAR SIDE MARKER LIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT TAIL LIGHT
SMALL LIGHT FUSE 32
STOP LIGHT HORN
TO TRAILER LIGHTING CONNECTOR (DIAGRAM 2 OF 2)
TO TRAILER LIGHTING CONNECTOR (DIAGRAM 2 OF 2) LEFT TAIL- LIGHT
TO UNDER-DASH FUSE/RELAY BOX (DIAGRAM 2 OF 2)
UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL)
UNDER-HOOD FUSE/RELAY BOX
W/ CRUISE CONTROL
W/ SPOILER
W/O CORNERING LIGHTS
W/O CRUISE CONTROL
W/O SPOILER
WHT/GRN WIRE
WHT/YEL WIRE
Exterior light circuit, coupe & sedan (2 of 2)
AUXILIARY FUSE HOLDER
BACK-UP LIGHTS
BLK WIRE
COMBINATION LIGHT SWITCH
FROM BRAKE LIGHT SWITCH
FROM FRONT TURN SIGNAL LIGHTS (DIAGRAM 1 OF 2)
FROM REAR TURN SIGNAL LIGHTS (DIAGRAM 1 OF 2)
FROM UNDER-DASH
FUSE 12
FUSE/RELAY BOX
GAUGE ASSEMBLY
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GROUND
HAZARD FUSE 35
HAZARD WARNING SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION
ILLUMINATION
LEFT
LEFT TURN INDICATOR LIGHT
OFF
RED WIRE
RED/BLK WIRE
RELAY OUT
RIGHT
RIGHT TURN INDICATOR LIGHT
SYSTEM
TO TRAILER LIGHTING CONNECTOR (DIAGRAM 2 OF 2)
TRAILER LIGHTING CONNECTOR
TURN SIGNAL SWITCH
TURN SIGNAL/ HAZARD RELAY
UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL)
UNDER-HOOD FUSE/RELAY BOX
WHT/GRN WIRE
YEL WIRE
YEL/WHT WIRE
