Honda Accord V (1993-1998) wind- shield wiper/ washer switch Wiring diagram
This page shows the only wiring diagram for the component.wind- shield wiper/ washer switch, which is found in the car Honda Accord V (1993-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wind- shield wiper/ washer switch (1 of 1)
11 3 IGN IN INT WIPER ON IN
6 7 DELAY INPUT DELAY INPUT
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
COMB- INATION WIPER SWITCH
COMBINED OPERATION WIPER/WASHER CIRCUIT
DELAY (W/VARIABLE INTERMITTENT WIPERS ONLY)
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GROUND
HOT IN ON OR START
INT LO MIST
INT WIPER CONTROL
INTEGRATED CONTROL UNIT
INTERMITTENT WIPER RELAY (BENEATH UNDER-HOOD FUSE/RELAY BOX)
J/C (BELOW LEFT HEADLAMP)
J/C (LEFT SIDE OF I/P)
MIST
OFF
PARK
PARK INPUT
RUN WIRE
UNDER-DASH FUSE/RELAY BOX
WASH
WASHER ON INPUT
WHT WIRE
WHT/YEL WIRE
WIND- SHIELD WIPER/ WASHER SWITCH
WINDSHIELD WASHER MOTOR (BEHIND LEFT SIDE OF FRONT BUMPER)
WINDSHIELD WIPER MOTOR (BEHIND LEFT SIDE OF AIR SCOOP)
WIPER/WASHER FUSE 6
Go to component -> Front wiper/washer circuit -> WIND- SHIELD WIPER/ WASHER SWITCH
