Honda Accord V (1993-1998) unlock out siren ctrl battery ignition Wiring diagram
This page shows the only wiring diagram for the component.unlock out siren ctrl battery ignition, which is found in the car Honda Accord V (1993-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram unlock out siren ctrl battery ignition (1 of 1)
ANTENNA
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
COUP, SEDAN
DISARM/ VALET SWITCH
DOOR LOCKS SYSTEM
DOOR LOCKS SYSTEM INTERIOR LIGHTS SYSTEM WARNING SYSTEM
DOOR OPEN IN TRUNK/TGATE OPEN IN HOOD SW IN DISARM/VALET SW IN LOCK OUT
EXTERIOR, INTERIOR LIGHTS SYSTEMS
GLASS BREAKAGE MICROPHONE
GRN WIRE
GRN/BLK WIRE
HOOD SWITCH
HORNS SYSTEM STARTING/CHARGING SYSTEM
HOT AT ALL TIMES
IGN SW FUSE 18
IGNITION KEY SWITCH
IGNITION SWITCH
LIGHT FLASHER RELAY (LEFT SIDE OF DASH)
LOCK
LT GRN/BLU WIRE
NCA WIRE
ORG/ WIRE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
SECURITY CONTROL UNIT (BELOW DRIVER'S SEAT)
SECURITY IN- LINE FUSE HOLDER (LEFT KICK PANEL)
SECURITY INDICATOR
SIREN
SIREN CTRL
SMALL LIGHT FUSE 32
STEERING LOCK ASSEMBLY
TRUNK LATCH SWITCH
UNDER- DASH FUSE/ RELAY BOX
UNDER- HOOD FUSE/ RELAY BOX
UNDER-DASH FUSE/RELAY BOX
UNLOCK OUT SIREN CTRL BATTERY IGNITION
WAGON
WARNING SYSTEM
WHT WIRE
WHT/RED WIRE
YEL/RED WIRE
Go to component -> Anti-theft circuit -> UNLOCK OUT SIREN CTRL BATTERY IGNITION
