Honda Accord V (1993-1998) turn signal/ hazard relay Wiring diagrams
This page contains all the electrical diagrams for the component. turn signal/ hazard relay, in which he is found in the car Honda Accord V (1993-1998). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
turn signal/ hazard relay wiring diagram (1 of 3)
AUXILIARY FUSE HOLDER
BACK-UP LIGHTS
BLK WIRE
COMBINATION LIGHT SWITCH
FROM BRAKE LIGHT SWITCH
FROM FRONT TURN SIGNAL LIGHTS (DIAGRAM 1 OF 2)
FROM REAR TURN SIGNAL LIGHTS (DIAGRAM 1 OF 2)
FROM UNDER-DASH
FUSE 12
FUSE/RELAY BOX
GAUGE ASSEMBLY
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GROUND
HAZARD FUSE 35
HAZARD WARNING SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION
ILLUMINATION
LEFT
LEFT TURN INDICATOR LIGHT
OFF
RED WIRE
RED/BLK WIRE
RELAY OUT
RIGHT
RIGHT TURN INDICATOR LIGHT
SYSTEM
TO TRAILER LIGHTING CONNECTOR (DIAGRAM 2 OF 2)
TRAILER LIGHTING CONNECTOR
TURN SIGNAL SWITCH
TURN SIGNAL/ HAZARD RELAY
UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL)
UNDER-HOOD FUSE/RELAY BOX
WHT/GRN WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Exterior light circuit, coupe & sedan (2 of 2) -> TURN SIGNAL/ HAZARD RELAY
turn signal/ hazard relay wiring diagram (2 of 3)
AUXILIARY FUSE HOLDER
BACK-UP LIGHTS
BLK WIRE
COMBINATION LIGHT SWITCH
FROM BRAKE LIGHT SWITCH
FROM FRONT TURN SIGNAL LIGHTS (DIAGRAM 1 OF 2)
FROM REAR TURN SIGNAL LIGHTS (DIAGRAM 1 OF 2)
FROM UNDER-DASH
FUSE 12
FUSE/RELAY BOX
GAUGE ASSEMBLY
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GROUND
HAZARD FUSE 35
HAZARD WARNING SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION
ILLUMINATION
LEFT
LEFT TURN INDICATOR LIGHT
OFF
RED WIRE
RED/BLK WIRE
RELAY OUT
RIGHT
RIGHT TURN INDICATOR LIGHT
SYSTEM
TO TRAILER LIGHTING CONNECTOR (DIAGRAM 2 OF 2)
TRAILER LIGHTING CONNECTOR
TURN SIGNAL SWITCH
TURN SIGNAL/ HAZARD RELAY
UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL)
UNDER-HOOD FUSE/RELAY BOX
WHT/GRN WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Exterior light circuit, wagon (2 of 2) -> TURN SIGNAL/ HAZARD RELAY
turn signal/ hazard relay wiring diagram (3 of 3)
ABS CONTROL UNIT
ABS FRONT FAIL-SAFE RELAY
ABS REAR FAIL-SAFE RELAY
BLK BLK WIRE
BLK WIRE
BLOWER MOTOR RELAY
CEILING LIGHT
CEILING LIGHT (COUPE, SEDAN W/0 MOONROOF)
CIGARETTE LIGHTER
CLUTCH SWITCH
COMBINATION LIGHT SWITCH
COUPE AND WAGON
CRUISE CONTROL ACTUATOR
CRUISE CONTROL MAIN SWITCH
DATA LINK CONNECTOR (DLC)
DIMMER RELAY
DRIVER'S POWER SEAT SWITCH (W/ 6 WAY POWER ADJUSTABLE SEAT) (1996)
DRIVER'S POWER SEAT SWITCH (W/ 6, 8-WAY POWER ADJUSTABLE SEAT)
DRIVER'S POWER SEAT UP-DOWN SWITCH (W/ POWER HEIGHT ADJUSTABLE SEAT)
DRIVER'S SEAT BELT SWITCH
EXHAUST GAS RECIRCULATION (EGR) CONTROL SOLENOID VALVE
FROM
GAUGE ASSEMBLY
GLOVE BOX LIGHT
HEATER CONTROL PANEL
HEATER FAN SWITCH
HIGH MOUNT BRAKE LIGHT
HIGH MOUNT BRAKE LIGHT (COUPE ONLY)
HORN RELAY
INTEGRATED CONTROL UNIT
INTERMITTENT WIPER RELAY
J/C
KEYLESS DOOR LOCK CONTROL UNIT (USA EX WAGON)
MOONROOF CLOSE RELAY
MOONROOF OPEN RELAY
MOONROOF SWITCH
POWER WINDOW RELAY
REAR WINDOW DEFOGGER SWITCH
SEDAN
SEDAN ONLY
SPOT- LIGHTS
STARTER CUT RELAY
STEERING LOCK ASSEMBLY
TURN SIGNAL/ HAZARD RELAY
UNDER- DASH FUSE/ RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
W/O MOON- ROOF
Go to component -> Ground distribution circuit (3 of 4) -> TURN SIGNAL/ HAZARD RELAY
