Honda Accord V (1993-1998) tachometer test connector Wiring diagram
This page shows the only wiring diagram for the component.tachometer test connector, which is found in the car Honda Accord V (1993-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tachometer test connector (1 of 1)
1 IND
2 IND
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH (MASTER CYLINDER)
BRAKE LAMP IND
BRAKE LIGHT FAILURE SENSOR (LEFT REAR OF TRUNK)
CANADA
CHARGE IND TO BULB CHECK (DIAGRAM 1 OF 2)
CRUISE CONTROL SYSTEM
CRUISE IND
DIMMING CIRCUIT
DRL CONTROL UNIT
ENGINE CONTROLS SYSTEM
FROM FUEL GAUGE (DIAGRAM 1 OF 2)
FROM OIL PRESS IND (DIAGRAM 1 OF 2)
FROM SEAT BELT IND (DIAGRAM 1 OF 2)
FUEL TANK UNIT (TOP OF FUEL TANK)
GAUGE ASSEMBLY
GRN/RED (OR GRN/WHT) WIRE
GRN/RED WIRE
GRN/WHT WIRE
IGNITION COIL (LEFT FRONT OF ENGINE)
IGNITION CONTROL MODULE (ICM) (RIGHT SIDE OF ENGINE IN DISTRIBUTOR)
J/C 429 (BEHIND LEFT SIDE OF I/P)
LEFT TURN IND
LT GRN/RED WIRE
N IND
ORG/ WIRE
P IND
PARKING BRAKE SWITCH (BELOW CENTER CONSOLE)
R IND
RIGHT REAR DOOR
RIGHT TURN IND
SAFETY INDICATOR CIRCUIT
SRS SRS IND CIRCUIT
TACHOMETER TEST CONNECTOR
TRANSMISSIONS SYSTEM
TRUNK/TAILGATE INDIC
UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL)
USA
VEHICLE SPEED SENSOR (RIGHT REAR OF TRANSMISSION)
WHT/GRN WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Instrument cluster circuit (2 of 2) -> TACHOMETER TEST CONNECTOR
