Honda Accord V (1993-1998) psp sw vss cyp m tdc m ckp m Wiring diagram

#4 #3 A/C PRESSURE SWITCH A/C RELAY AFSA ACS ATP PN STS CYP P TDC P CKP P AFSB ALTC FAS PCS PFSW ALTERNATOR BARO OUT K-LINE ALT F TPS ECT IAT MAP BLK BLK WIRE BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/WHT WIRE CYP TDC TDC/CYP SENSOR (RIGHT FRONT OF ENGINE) DATA LINK CONNECTOR (BELOW CENTER CONSOLE) EGRL ATCHK EL EGRL ENGINE CONTROL MODULE (RIGHT FRONT OF FLOOR, UNDER CARPET) ES IAB SOL ICM FLR IACV FUEL INJECTORS FUEL PUMP GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/RED WIRE GRN/WHT WIRE IGNITION INPUT GROUND INJECTOR RESISTOR (LEFT REAR OF ENGINE COMPARTMENT) JUNCTION JUNCTION CONNECTOR LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE MCS FANC ORG/ WIRE ORG/BLK WIRE ORG/BLU WIRE PNK/BLU WIRE PSP SW VSS CYP M TDC M CKP M RADIATOR FAN CONTROL MODULE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE SERVICE CHECK CONNECTOR (BEHIND RIGHT SIDE OF DASH) THROTTLE POSITION SENSOR (TOP LEFT OF ENGINE) TRANSAXLE VBU VEHICLE SPEED OUTPUT VEHICLE SPEED SENSOR (RIGHT REAR OF TRANSMISSION) VREF WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/WHT WIRE
