Honda Accord V (1993-1998) moonroof switch Wiring diagrams

This page contains all the electrical diagrams for the component. moonroof switch, in which he is found in the car Honda Accord V (1993-1998). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram moonroof switch (1 of 4)

Wiring diagram moonroof switch for Honda Accord V (1993-1998) (1 of 4)

Get access

ABS CONTROL UNIT ABS FRONT FAIL-SAFE RELAY ABS REAR FAIL-SAFE RELAY BLK BLK WIRE BLK WIRE BLOWER MOTOR RELAY CEILING LIGHT CEILING LIGHT (COUPE, SEDAN W/0 MOONROOF) CIGARETTE LIGHTER CLUTCH SWITCH COMBINATION LIGHT SWITCH COUPE AND WAGON CRUISE CONTROL ACTUATOR CRUISE CONTROL MAIN SWITCH DATA LINK CONNECTOR (DLC) DIMMER RELAY DRIVER'S POWER SEAT SWITCH (W/ 6 WAY POWER ADJUSTABLE SEAT) (1996) DRIVER'S POWER SEAT SWITCH (W/ 6, 8-WAY POWER ADJUSTABLE SEAT) DRIVER'S POWER SEAT UP-DOWN SWITCH (W/ POWER HEIGHT ADJUSTABLE SEAT) DRIVER'S SEAT BELT SWITCH EXHAUST GAS RECIRCULATION (EGR) CONTROL SOLENOID VALVE FROM GAUGE ASSEMBLY GLOVE BOX LIGHT HEATER CONTROL PANEL HEATER FAN SWITCH HIGH MOUNT BRAKE LIGHT HIGH MOUNT BRAKE LIGHT (COUPE ONLY) HORN RELAY INTEGRATED CONTROL UNIT INTERMITTENT WIPER RELAY J/C KEYLESS DOOR LOCK CONTROL UNIT (USA EX WAGON) MOONROOF CLOSE RELAY MOONROOF OPEN RELAY MOONROOF SWITCH POWER WINDOW RELAY REAR WINDOW DEFOGGER SWITCH SEDAN SEDAN ONLY SPOT- LIGHTS STARTER CUT RELAY STEERING LOCK ASSEMBLY TURN SIGNAL/ HAZARD RELAY UNDER- DASH FUSE/ RELAY BOX UNDER-HOOD FUSE/RELAY BOX W/O MOON- ROOF

Go to component -> Ground distribution circuit (3 of 4) -> MOONROOF SWITCH

Wiring diagram moonroof switch (2 of 4)

Wiring diagram moonroof switch for Honda Accord V (1993-1998) (2 of 4)

Get access

8 BULBS A/T GEAR POSITION CONSOLE LIGHT A/T GEAR POSITION INDICATOR ANTI-THEFT SYSTEM (OPTIONAL) ASHTRAY LIGHT BLK WIRE CIGARETTE LIGHTER CLOCK COMBINATION LIGHT SWITCH CRUISE CONTROL MAIN SWITCH DASH LIGHTS BRIGHTNESS CONTROLLER (BEHIND LEFT SIDE OF I/P) DIM SIGNAL INPUT DIMMER DIMMING CIRCUIT DRIVER'S VANITY MIRROR LIGHT (OPTIONAL) GAUGE ASSEMBLY GAUGE ASSEMBLY LIGHTS GLOVE BOX LIGHT GRY WIRE HAZARD WARNING SWITCH HEAD OFF PARK HEADLIGHT SWITCH HEATER CONTROL PANEL HOT AT ALL TIMES J/C LIGHTER ILLUM. MOONROOF SWITCH OFF PASSENGER'S VANITY MIRROR LIGHT (OPTIONAL) REAR WINDOW DEFOGGER SWITCH RED WIRE RED/BLK WIRE RED/GRN WIRE SMALL LIGHT FUSE 32 STEREO RADIO/ CASSETTE PLAYER UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL) UNDER-HOOD FUSE/RELAY BOX

Go to component -> Instrument illumination circuit -> MOONROOF SWITCH

Wiring diagram moonroof switch (3 of 4)

Wiring diagram moonroof switch for Honda Accord V (1993-1998) (3 of 4)

Get access

8 2 12 GROUND IGNITION BATTERY BACK-UP LIGHTS FUSE 1 BATTERY FUSE 15 BLK WIRE CLOSE DRIVER'S DOOR SWITCH GRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT IN ON OR START INTEGRATED CONTROL UNIT INTERIOR LIGHT FUSE 37 J/C (RIGHT SIDE OF I/P) LFT FRT DOOR SW IN MOON- ROOF SWITCH LIGHT MOONROOF CLOSE RELAY (BEHIND LEFT KICK PANEL) MOONROOF MOTOR (CENTER OF ROOF) MOONROOF OPEN RELAY (BEHIND LEFT KICK PANEL) MOONROOF SWITCH PASS- ENGER'S DOOR SWITCH POWER WINDOW FR-L FUSE 28 POWER WINDOW KEY-OFF TIMER CIRCUIT POWER WINDOW RELAY RED WIRE RED/BLK WIRE RELAY CONTROL RT FRT DOOR SW IN SUN ROOF FUSE 29 UNDER- DASH FUSE/ RELAY BOX UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX WHT/BLU WIRE WHT/RED WIRE YEL WIRE

Go to component -> Moonroof circuit -> MOONROOF SWITCH
