Honda Accord V (1993-1998) horn relay (under middle Wiring diagram
This page shows the only wiring diagram for the component.horn relay (under middle, which is found in the car Honda Accord V (1993-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram horn relay (under middle (1 of 1)
BLK WIRE
BLU WIRE
CABLE REEL
CRUISE CON- TROL SYSTEM
CRUISE CONTROL SET/
HORN RELAY (UNDER MIDDLE
HOT AT ALL TIMES
J/C
JUMPER CONNECTOR
LAY BOX
LEFT HORN (MIDDLE OF ENGINE COMPT)
LEFT HORN SWITCH
LT GRN WIRE
NCA WIRE
OF DASH)
RED WIRE
RESUME + SWITCH
RIGHT HORN (MIDDLE OF ENGINE COMPT)
RIGHT HORN SWITCH
SECURITY SYSTEM CONNECTOR (OPTION) (CANADA)
STEERING WHEEL)
STOP LIGHT, HORN FUSE 30
UNDER HOOD FUSE/RE-
W/ CRUISE
W/O CRUISE
WHT WIRE
YEL WIRE
Go to component -> Horn circuit -> HORN RELAY (UNDER MIDDLE
