Honda Accord V (1993-1998) gauge assembly low oil pressure indicator light Wiring diagram
This page shows the only wiring diagram for the component.gauge assembly low oil pressure indicator light, which is found in the car Honda Accord V (1993-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gauge assembly low oil pressure indicator light (1 of 1)
ALTERNATOR
ANTI-THEFT SYSTEM
BEEPER
BLK WIRE
BLU WIRE
BLU/WHT WIRE
CHIME
COMBINATION LIGHT SWITCH
COUPE, WAGON, SEDAN
DRIVER'S DOOR SWITCH
DRIVER'S SEAT BELT SWITCH
ENGINE OIL PRESSURE INDICATOR FLASHER UNIT
ENGINE OIL PRESSURE SWITCH (REAR OF ENGINE)
FUSE 1
GAUGE ASSEMBLY LOW OIL PRESSURE INDICATOR LIGHT
GRN/ORG WIRE
HEAD
HEAD- LIGHTS SYSTEM
HEADLIGHT SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION KEY SWITCH
INTEGRATED CONTROL UNIT
J/C
KEY-IN/ SEAT BELT BEEPER CIRCUIT
LIGHTS-ON REMINDER CIRCUIT
OFF PARK
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
SEAT BELT REMINDER LIGHT
STEERING LOCK ASSEMBLY
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Warning system circuits -> GAUGE ASSEMBLY LOW OIL PRESSURE INDICATOR LIGHT
