Honda Accord V (1993-1998) front up-down motor Wiring diagrams
This page contains all the electrical diagrams for the component. front up-down motor, in which he is found in the car Honda Accord V (1993-1998). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
front up-down motor wiring diagram (1 of 2)
BACK- WARD
BLK WIRE
BLU WIRE
BLU/YEL WIRE
DOWN
DRIVER'S POWER SEAT SWITCH
EXCEPT 1997
FOR- WARD
FRONT UP-DOWN MOTOR
GRN WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
J/C (BELOW LEFT FRONT SEAT)
POWER SEAT FUSE 27
POWER SEAT HEIGHT FUSE 31
REAR UP-DOWN MOTOR
RED WIRE
RED/YEL WIRE
SLIDE MOTOR
UNDER-HOOD FUSE/RELAY BOX
WHT/GRN WIRE
WHT/RED WIRE
Go to component -> 6-way power seat circuit -> FRONT UP-DOWN MOTOR
front up-down motor wiring diagram (2 of 2)
BACK- WARD
BLK WIRE
BLU WIRE
BLU/YEL WIRE
DOWN
DRIVER'S POWER SEAT SWITCH
FOR- WARD
FRONT UP-DOWN MOTOR
GRN WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
J/C (BELOW LEFT FRONT SEAT)
POWER SEAT FUSE 27
POWER SEAT HEIGHT FUSE 31
REAR UP-DOWN MOTOR
RECLINE MOTOR
RED WIRE
RED/YEL WIRE
SLIDE MOTOR
UNDER-HOOD FUSE/RELAY BOX
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> 6-way & recliner power seat circuit -> FRONT UP-DOWN MOTOR
