Honda Accord V (1993-1998) except dx Wiring diagram
This page shows the only wiring diagram for the component.except dx, which is found in the car Honda Accord V (1993-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram except dx (1 of 1)
1996 EX WAGON
3 2 (MOONROOF) RIGHT REAR DOOR COURTESY LIGHT
A/C COMPRESSOR CLUTCH RELAY
ALL 1995,
BACK-UP RADIO FUSE 39
BLK WIRE
CELING LIGHT UNDER-DASH FUSE/RELAY BOX
CIGARETTE LIGHTER
CIGARETTE LIGHTER RELAY (BEHIND FRONT CONSOLE)
CLOCK TRANSMISSION CONTROL MODULE (TCM)
COMBINATION LIGHT SWITCH
CONDENSER FAN FUSE 34
CONDENSER FAN RELAY
COUPE, SEDAN, WAGON
DATA LINK CONNECTOR (DLC)
DOOR LOCK FUSE 38
DRIVER'S POWER SEAT UP/DOWN SWITCH DRIVER'S POWER SEAT SWITCH
DRIVERS DOOR COURTESY LIGHT RIGHT FRONT DOOR COURTESY LIGHT
ECU FUSE 33
ENGINE CONTROL MODULE (ECM) OR
EXCEPT DX
FROM FUSE 11 (DIAGRAM 3 OF 4)
FROM FUSE 23 (DIAGRAM 1 OF 4)
FROM FUSE 36 (DIAGRAM 2 OF 4)
GRN WIRE
HEADLIGHT RELAY
INTEGRATED CONTROL UNIT
INTERIOR LIGHT FUSE 37
KEYLESS DOOR LOCK CONTROL UNIT
MOONROOF OPEN RELAY MOONROOF CLOSE RELAY
PGM-FI MAIN RELAY
POWER ANTENNA MOTOR LEFT REAR DOOR COURTESY LIGHT (SEDAN, WAGON)
POWER DOOR LOCK CONTROL UNIT
POWER SEAT RECLINER FUSE 31
POWER WINDOW RELAY
POWERTRAIN CONTROL MODULE (PCM)
RADIATOR FAN CONTROL MODULE
RADIO CIGAR LIGHTER FUSE 36
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
SECURITY SYSTEM CONNECTOR (CANADA)
SMALL LIGHT FUSE 32
SPOT- LIGHTS
STEREO RADIO/ CASSETTE PLAYER
SUN ROOF FUSE 29
TO FUSE 37 (DIAGRAM 2 OF 4)
TRUNK LIGHT CARGO LIGHT
UNDER-HOOD FUSE/RELAY BOX
W/ 6, 8-WAY POWER ADJUSTABLE SEAT W/ POWER HEIGHT ADUSTABLE SEAT
W/ KEYLESS ENTRY
W/ POWER DOOR LOCKS
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
Go to component -> Power distribution circuit (2 of 4) -> EXCEPT DX
