Honda Accord V (1993-1998) brake light failure sensor Wiring diagram
This page shows the only wiring diagram for the component.brake light failure sensor, which is found in the car Honda Accord V (1993-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram brake light failure sensor (1 of 1)
1995 ONLY
BLK BLK BLK WIRE
BLK BLK WIRE
BLK WIRE
BLK/RED WIRE
BRAKE LIGHT FAILURE SENSOR
FUEL PUMP
FUEL TANK UNIT
HIGH MOUNT BRAKE LIGHT (W/ SPOILER)
LEFT BACK-UP LIGHT
LEFT BACK-UP LIGHT (1995)
LEFT BACK-UP LIGHT (1996)
LEFT BRAKE LIGHT/ TAILLIGHT
LEFT LICENSE LIGHT
LEFT REAR SIDE MARKER LIGHT
LEFT REAR TURN SIGNAL LIGHT
LEFT TAIL- LIGHT (1996)
POWER ANTENNA MOTOR
POWER ANTENNA MOTOR (1995 SEDAN)
REAR WIPER MOTOR
RIGHT BACK-UP LIGHT
RIGHT BACK-UP LIGHT (1995)
RIGHT BACK-UP LIGHT (1996)
RIGHT BRAKE LIGHT/ TAILIGHT
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT LICENSE LIGHT
RIGHT REAR SIDE MARKER LIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT TAIL- LIGHT (1996)
TAILGATE DOOR LOCK KEY CYLINDER SWITCH
TAILGATE LATCH ASSEMBLY
TRAILER CONNECTOR
TRUNK LATCH SWITCH
WAGON ONLY
WHT/BLU WIRE
Go to component -> Ground distribution circuit (4 of 4) -> BRAKE LIGHT FAILURE SENSOR
