Honda Accord V (1993-1998) brake indicator output Wiring diagram
This page shows the only wiring diagram for the component.brake indicator output, which is found in the car Honda Accord V (1993-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram brake indicator output (1 of 1)
BACK UP, METER LIGHTS, TURN SIGNALS FUSE 1
BATTERY FUSE 15
BATTERY INPUT
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRAKE INDICATOR OUTPUT
COMBINATION LIGHT SWITCH
CORNER OF ENG. COMPT.)
DAY LIGHTS FUSE 10
DAYTIME RUNNING LIGHTS CONTROL UNIT (RIGHT SIDE OF I/P)
DIMMER RELAY
DIMMER SWITCH
FLASH TO PASS SWITCH
FOG LIGHT IN LINE FUSE (RIGHT FRONT OF ENG. COMPT.)
FOG LIGHT SWITCH
FUSIBLE LINK
GAUGE ASSEMBLY
GAUGE ASSEMBLY DAYTIME RUNNING LIGHTS INDICATOR
GRN WIRE
GRN/WHT WIRE
GROUND
HEAD OFF PARK
HEADLIGHT RELAY
HEADLIGHT RELAY CONTROL
HEADLIGHT SWITCH
HIGH BEAM INDICATOR LIGHT
HIGH BEAM OFF INPUT
HIGH BEAM REQUEST
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
IGNITION INPUT
INDER-DASH FUSE/RELAY BOX
INDICATOR LIGHT CONTROL
INSTRUMENT CLUSTER SYSTEM (BRAKE INDICATOR)
LEFT HEADLIGHT
LEFT HEADLIGHT FUSE 19
LEFT HIGH BEAM CONTROL
LEFT LOW BEAM INPUT
LO HI
ORG/ WIRE
ORG/WHT WIRE
PARKING BRAKE INPUT
PARKING BRAKE SWITCH
PNK PNK RIGHT FOG LIGHT LEFT FOG LIGHT WIRE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/ORG WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY BOX (LEFT KICK PANEL)
RIGHT HEADLIGHT
RIGHT HEADLIGHT FUSE 20
RIGHT HIGH BEAM CONTROL
RIGHT LOW BEAM INPUT
RUNNING LIGHT FUSE 23
UNDER-DASH FUSE/
UNDER-HOOD FUSE/RELAY BOX (RIGHT REAR
WHT WIRE
YEL WIRE
Go to component -> Headlight circuit, with drl -> BRAKE INDICATOR OUTPUT
