Honda Accord V (1993-1998) auto down up up Wiring diagram
This page shows the only wiring diagram for the component.auto down up up, which is found in the car Honda Accord V (1993-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auto down up up (1 of 1)
2 1 IGNITION LFT FRT DOOR SW IN
AUTO DOWN
AUTO DOWN UP UP
BATTERY
BLK WIRE
BLU RED/ WIRE
BLU WIRE
BLU/BLK WIRE
BLU/YEL WIRE
COUPE
DOWN
DRIVER'S POWER WINDOW MOTOR
FUSE 1
FUSE 15
FUSE 24
FUSE 25
FUSE 26
FUSE 28
FUSE 37
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GROUND
HOT AT ALL TIMES
HOT IN ON OR START
LEFT FRONT
LEFT REAR
MAIN SWITCH
MASTER POWER WINDOW SWITCH
OFF DOWN
OFF OFF DOWN DOWN
ON OFF
POWER WINDOW KEY-OFF TIMER CIRCUIT MODULE (INTEGRATED CONTROL UNIT)
POWER WINDOW RELAY
PULSER
RED WIRE
RED YEL/ WIRE
RELAY CONTROL
RIGHT FRONT
RIGHT REAR
RT FRT DOOR SW IN
SEDAN
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
UP OFF DOWN
UP UP OFF OFF
UP UP OFF OFF DOWN
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
WHT/YEL WIRE
WINDOW CONTROL UNIT
YEL WIRE
YEL/GRN WIRE
Go to component -> Power window circuit (1 of 2) -> AUTO DOWN UP UP
