Car Wiring Diagrams for Compass circuit for Honda Accord IX facelift (2014-2019)

AUDIO UNIT/ AUDIO NAVIGATION UNIT BLK WIRE BRN WIRE CENTER JUNCTION BOX DRIVER'S JUNCTION BOX ELECTRICAL COMPASS UNIT FUSE 37 FUSE 5 GRN WIRE HOT W/ ACCESSORY SUB RELAY ENERGIZED LT BLU WIRE ORG/ WIRE POWER DISTRIBUTION SYSTEM PPL RED WIRE RELAY ENERGIZED SEDAN COUPE HYBRID EXCEPT HYBRID TAN WIRE UNDER-DASH FUSE/RELAY BOX
