Car Wiring Diagrams for Memory systems circuit, hybrid for Honda Accord IX facelift (2014-2019)

BACKWARD BATTERY CONDITION MONITOR MODULE BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DOWN DRIVER'S JUNCTION BOX DRIVER'S POWER SEAT ADJUSTMENT SWITCH DRIVER'S SEAT FRONT UP-DOWN MOTOR DRIVER'S SEAT REAR UP-DOWN MOTOR DRIVER'S SEAT RECLINE MOTOR DRIVER'S SEAT SLIDE MOTOR FORWARD/ FRONT UP-DOWN SWITCH FUSE 36 FUSE 7 FUSE 15 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START KEYLESS ACCESS CONTROL UNIT LT BLU WIRE ORG/ WIRE PNK WIRE POWER SEAT CONTROL UNIT/ POWER SEAT ADJUSTMENT SWITCH PPL REAR UP-DOWN SWITCH RECLINE SWITCH RED WIRE SLIDE SWITCH UNDER-DASH FUSE/RELAY BOX WHT WIRE YEL WIRE

BLK WIRE BLU WIRE CENTER JUNCTION BOX COMPUTER DATA LINES SYSTEM CONTROL UNIT) DRIVING POSITION MEMORY SWITCH FUSE 1 FUSE 21 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON ILLUMINATION IND 1 IND 2 LT GRN WIRE MICU PCM PNK WIRE POSITION 1 POSITION 2 POWER WINDOW MASTER SWITCH PPL RED WIRE SET- TRANSMISSION RANGE SWITCH UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE
