Honda Accord IX facelift (2014-2019) cmbs off switch/rdm switch Wiring diagram
This page shows the only wiring diagram for the component.cmbs off switch/rdm switch, which is found in the car Honda Accord IX facelift (2014-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cmbs off switch/rdm switch (1 of 1)
AS IND
BLK WIRE
BLU WIRE
CENTER JUNCTION BOX
CLIMATE CONTROL UNIT
CMBS OFF SWITCH/RDM SWITCH
COMPUTER DATA LINES SYSTEM
CONTROL UNIT)
DRIVING POSITION MEMORY SWITCH
ECON SWITCH
EV SWITCH
FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
GRN WIRE
GRY WIRE
HAZARD WARNING SWITCH
IND 1
IND 2
LEFT REAR POWER WINDOW SWITCH
LT GRN WIRE
PARKING, BACKUP SENSOR SWITCH
PNK WIRE
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
PPL
RDM SWITCH
RED WIRE
RIGHT REAR POWER WINDOW SWITCH
SPORT MODE SWITCH
TAN WIRE
VSA OFF SWITCH/ ACOUSTIC VEHICLE ALERTING OFF SWITCH
VSA/CMBS OFF SWITCH
W/ ACC
W/ NAVIGATION
W/O ACC
W/O ACC W/ ACC
Go to component -> Instrument illumination circuit, hybrid (3 of 3) -> CMBS OFF SWITCH/RDM SWITCH
