Supplemental restraints circuit, hybrid for Honda Accord IX (2012-2016)
Supplemental restraints circuit, hybrid (1 of 3)
BATTERY CONDITION MONITOR MODULE (TOP LEFT REAR OF BATTERY PACK ASSEMBLY)
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL (IN STEERING COLUMN)
CENTER JUNCTION BOX
COMPUTER DATA LINES SYSTEM
DRIVER'S AIR BAG INFLATOR (PLUG-IN HYBRID: IN STEERING WHEEL)
DRIVER'S JUNCTION BOX
FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
FRONT PASSENGER'S AIR BAG INFLATOR (BEHIND GLOVE BOX)
FUSE FUSE
GRN WIRE
GRY WIRE
HOT IN ON OR START
HYBRID, PLUG-IN HYBRID
LEFT FRONT IMPACT SENSOR (LEFT SIDE OF RADIATOR SUPPORT)
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PPL
RED WIRE
RIGHT FRONT IMPACT SENSOR (RIGHT SIDE OF RADIATOR SUPPORT)
SRS UNIT (UNDER FRONT OF CENTER CONSOLE)
UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH)
WHT WIRE
YEL WIRE
Supplemental restraints circuit, hybrid (2 of 3)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FORCED TURN ON CIRCUIT
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH (INTEGRAL TO FRONT PASSENGER'S
FRONT PASSENGER'S WEIGHT SENSOR UNIT
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HYBRID, PLUG-IN HYBRID
INDICATOR DRIVE CIRCUIT
LT GRN WIRE
MAIN CIRCUIT
ORG/ WIRE
PLUG-IN HYBRID
RED WIRE
SEAT BELT BUCKLE ASSEMBLY)
SEAT BELT REMINDER INDICATOR
SIDE AIR BAG CUT-OFF INDICATOR
SRS INDICATOR
WHT WIRE
YEL WIRE
Supplemental restraints circuit, hybrid (3 of 3)
BLK WIRE
BLU WIRE
BRN WIRE
CURTAIN AIR BAG INFLATOR (ROOF RAIL, ABOVE RIGHT REAR DOOR)
DRIVER'S SEAT POSITION SENSOR (UNDER RIGHT SIDE OF DRIVER'S SEAT)
FUSE
GRN WIRE
GRY WIRE
HOT IN ON OR START
HYBRID, PLUG-IN HYBRID
LEFT SIDE IMPACT SENSOR (FIRST) (BASE OF LEFT "B" PILLAR)
LEFT SIDE IMPACT SENSOR (SECOND) (BASE OF LEFT "C" PILLAR)
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK 2 1 WIRE
PNK WIRE
PPL
REAR SAFING SENSOR (UNDER CENTER OF REAR SEATS)
RED WIRE
RIGHT SIDE IMPACT SENSOR (FIRST) (BASE OF RIGHT "B" PILLAR)
RIGHT SIDE IMPACT SENSOR (SECOND) (BASE OF RIGHT "C" PILLAR)
SRS UNIT (UNDER FRONT OF CENTER CONSOLE)
UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH)
WHT WIRE
YEL WIRE
