Premium radio circuit, except hybrid without navigation for Honda Accord IX (2012-2016)

Premium radio circuit, except hybrid without navigation (1 of 5)

Accord Honda IX (2012-2016): Premium radio circuit, except hybrid without navigation (1 of 5)

Get access

AUDIO REMOTE SWITCH AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE CABLE REEL (IN STEERING COLUMN) CENTER JUNCTION BOX CH+ SWITCH COMPUTER DATA LINES SYSTEM DISP SWITCH FUSE FUSE 22 FUSE 21 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACCESSORY SUB RELAY ENERGIZED LT BLU WIRE LT GRN WIRE NCA WIRE PNK 4 5 WIRE PNK 8 9 WIRE PNK PNK WIRE PNK WIRE PPL PPL 10 11 REAR ANC/ACTIVE SOUND CONTROL MICROPHONE (UNDER MIDDLE OF REAR SHELF) RED WIRE SOURCE SWITCH UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH) UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT) USB PORT VOLUME DOWN SWITCH VOLUME UP SWITCH WHT WIRE YEL WIRE

Premium radio circuit, except hybrid without navigation (2 of 5)

Accord Honda IX (2012-2016): Premium radio circuit, except hybrid without navigation (2 of 5)

Get access

ANC/ACTIVE SOUND CONTROL UNIT (CENTER OF DASH) BLK WIRE BLU WIRE BRN WIRE CENTER JUNCTION BOX COMPUTER DATA LINES SYSTEM FUSE GRN WIRE GRY WIRE HOT W/ LT BLU WIRE LT GRN WIRE MICU ORG/ WIRE PNK 10 11 WIRE PNK 12 13 WIRE PNK 4 5 WIRE PNK 8 9 WIRE PNK WIRE PPL PPL 10 11 RED WIRE STEREO AMPLIFIER (RIGHT END OF DASH) UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH) WHT WIRE YEL WIRE

Premium radio circuit, except hybrid without navigation (3 of 5)

Accord Honda IX (2012-2016): Premium radio circuit, except hybrid without navigation (3 of 5)

Get access

AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE DRIVER'S DOOR SPEAKER FRONT PASSENGER'S DOOR SPEAKER FUSE 4 FUSE 1 OF DASH) GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT REAR SPEAKER LEFT TWEETER LT BLU WIRE LT GRN WIRE NAVIGATION SYSTEM ORG/ WIRE PNK 10 11 WIRE PNK 12 13 WIRE PNK WIRE PPL PPL 1 2 RED WIRE RIGHT REAR SPEAKER RIGHT TWEETER SUBWOOFER UNDER-DASH SUB FUSE BOX (LEFT END WHT WIRE YEL WIRE

Premium radio circuit, except hybrid without navigation (4 of 5)

Accord Honda IX (2012-2016): Premium radio circuit, except hybrid without navigation (4 of 5)

Get access

AM/FM ANTENNA AMPLIFIER AMP AUDIO UNIT/AUDIO NAVIGATION UNIT AUXILIARY JACK ASSEMBLY BLK WIRE BRN WIRE FRONT HFL-ANC/ACTIVE SOUND CONTROL MICROPHONE GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE NAVIGATION SYSTEM NCA WIRE ORG/ WIRE PNK 14 15 WIRE PNK PPL WIRE PNK WIRE PPL PPL 1 2 RED WIRE TUNER UNIT WHT WIRE XM ANTENNA YEL WIRE

Premium radio circuit, except hybrid without navigation (5 of 5)

Accord Honda IX (2012-2016): Premium radio circuit, except hybrid without navigation (5 of 5)

Get access

AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE COUPE GRN WIRE GRY WIRE HANDSFREELINK CONTROL UNIT (LOWER CENTER OF DASH) LT BLU WIRE LT GRN WIRE MULTI INFORMATION DISPLAY UNIT NCA WIRE PNK 14 15 WIRE PNK PPL WIRE PNK WIRE PPL RED WIRE WHT WIRE YEL WIRE
