Premium radio circuit, except hybrid with navigation for Honda Accord IX (2012-2016)

Premium radio circuit, except hybrid with navigation (1 of 5)

Accord Honda IX (2012-2016): Premium radio circuit, except hybrid with navigation (1 of 5)

Get access

AUDIO REMOTE SWITCH AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE CABLE REEL (IN STEERING COLUMN) CENTER JUNCTION BOX CH+ SWITCH CH- SWITCH COMPUTER DATA LINES SYSTEM DISP SWITCH FUSE 37 FUSE FUSE (LEFT SIDE OF ENGINE COMPT) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACCESSORY SUB RELAY ENERGIZED LT BLU WIRE LT GRN WIRE MICU NCA WIRE PNK 10 11 WIRE PNK 6 7 WIRE PNK PNK WIRE PNK WIRE PPL PPL 12 13 PPL PPL 2 3 REAR ANC/ACTIVE SOUND CONTROL MICROPHONE (UNDER MIDDLE OF REAR SHELF) RED WIRE SOURCE SWITCH UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH) UNDER-HOOD FUSE/RELAY BOX USB PORT VOLUME DOWN SWITCH VOLUME UP SWITCH WHT WIRE YEL WIRE

Premium radio circuit, except hybrid with navigation (2 of 5)

Accord Honda IX (2012-2016): Premium radio circuit, except hybrid with navigation (2 of 5)

Get access

1 2 PPL ANC/ACTIVE SOUND CONTROL UNIT (CENTER OF DASH) AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE CENTER JUNCTION BOX COMPUTER DATA LINES SYSTEM DRIVER'S JUNCTION BOX GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE NAVIGATION SWITCH PANEL ORG/ WIRE PARKING BRAKE SWITCH PCM (2.4L: LEFT SIDE OF ENGINE COMPT) PNK 10 11 WIRE PNK 13 14 WIRE PNK 15 16 WIRE PNK 6 7 WIRE PNK WIRE PPL PPL 12 13 PPL PPL 2 3 RED WIRE STEREO AMPLIFIER (RIGHT END OF DASH) WHT WIRE YEL WIRE

Premium radio circuit, except hybrid with navigation (3 of 5)

Accord Honda IX (2012-2016): Premium radio circuit, except hybrid with navigation (3 of 5)

Get access

1 2 PPL ANTENNA AMPLIFIER AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE COMBINATION LIGHT SWITCH DRIVER'S DOOR SPEAKER FRONT HFL- NAVIGATION- ANC/ACTIVE SOUND CONTROL MICROPHONE FRONT PASSENGER'S DOOR SPEAKER FUSE FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT REAR SPEAKER LEFT TWEETER LT BLU WIRE LT GRN WIRE NCA WIRE ORG/ WIRE PNK 13 14 WIRE PNK 15 16 WIRE PNK WIRE PPL PPL 1 2 RDS/TMC ANTENNA MODULE RED WIRE RIGHT REAR SPEAKER RIGHT TWEETER SUBWOOFER UNDER-DASH SUB FUSE BOX (LEFT END OF DASH) WHT WIRE YEL WIRE

Premium radio circuit, except hybrid with navigation (4 of 5)

Accord Honda IX (2012-2016): Premium radio circuit, except hybrid with navigation (4 of 5)

Get access

AM/FM ANTENNA AMPLIFIER AMP AUDIO UNIT/AUDIO NAVIGATION UNIT AUXILIARY JACK ASSEMBLY BLK WIRE BRN WIRE GRN WIRE GRY WIRE LANE WATCH CAMERA LT BLU WIRE NCA WIRE PNK PPL WIRE PNK WIRE PPL PPL 1 2 REARVIEW CAMERA (CENTER REAR OF LUGGAGE COMPT LID) RED WIRE TUNER UNIT WHT WIRE XM ANTENNA YEL WIRE

Premium radio circuit, except hybrid with navigation (5 of 5)

Accord Honda IX (2012-2016): Premium radio circuit, except hybrid with navigation (5 of 5)

Get access

AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE GRN WIRE GRY WIRE HANDSFREELINK CONTROL UNIT (LOWER CENTER OF DASH) LT BLU WIRE LT GRN WIRE MULTI INFORMATION DISPLAY UNIT NCA WIRE PNK PPL WIRE PNK WIRE PPL RED WIRE WHT WIRE YEL WIRE
