Telematics circuit for Honda Accord IX (2012-2016)

Telematics circuit (1 of 2)

Accord Honda IX (2012-2016): Telematics circuit (1 of 2)

Get access

BLK WIRE BLU WIRE BRN WIRE CABLE REEL (IN STEERING COLUMN) CENTER JUNCTION BOX COMPUTER DATA LINES SYSTEM CONTROL UNIT) FRONT HFL- NAVIGATION-ANC/ ACTIVE SOUND CONTROL MICROPHONE (IN ROOF CONSOLE) FUSE GRN WIRE GRY WIRE HANG-UP BACK SWITCH HFL/HFL- NAVIGATION VOICE CONTROL SWITCH HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX FUSE (LEFT REAR OF ENGINE COMPT) J/C LT BLU WIRE LT GRN WIRE PICK-UP SWITCH PNK WIRE PPL RED WIRE RELAY ENERGIZED TALK SWITCH TELEMATICS CONTROL UNIT (RIGHT END OF DASH) UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH) WHT WIRE YEL WIRE

Telematics circuit (2 of 2)

Accord Honda IX (2012-2016): Telematics circuit (2 of 2)

Get access

AM/FM/TEL/ GPS ANTENNA (GPS ANTENNA: TOP CENTER OF DASH) AUDIO- NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM PNK WIRE FUSE GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE PNK WIRE PPL PPL PPL RED WIRE TUNER UNIT (RIGHT SIDE OF LUGGAGE COMPT) YEL WIRE
