Lane watch camera circuit, except hybrid for Honda Accord IX (2012-2016)
Lane watch camera circuit, except hybrid
AUDIO UNIT/ AUDIO NAVIGATION UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX
COMBINATION LIGHT SWITCH
COMPUTER DATA LINES SYSTEM
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY FUSE BOX (LEFT SIDE OF ENGINE COMPT)
HOT W/ ACCESSORY SUB RELAY ENERGIZED
LANE WATCH CAMERA
LT BLU WIRE
MICU
MULTI INFORMATION DISPLAY UNIT
NAVIGATION SWITCH PANEL (IF EQUIPPED)
NCA WIRE
PNK COMPUTER DATA LINES SYSTEM WIRE
PNK WIRE
PPL
PPL/ PPL/ PPL/
RED WIRE
UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH)
WHT WIRE
YEL WIRE
