Lane departure warning circuit, hybrid for Honda Accord IX (2012-2016)
Lane departure warning circuit, hybrid
ACC UNIT
BLK WIRE
BRN WIRE
CENTER JUNCTION BOX
CHARGE LID ILLUMINATION LAMP/CHARGE INDICATOR
COMPUTER DATA LINES SYSTEM
CONTROLLER AREA NETWORK CONTROLLER CPU/POWER SUPPLY CIRCUIT/
CONTROLLER AREA NETWORK CONTROLLER POWER SUPPLY CIRCUIT/
DRIVE CIRCUIT INDICATOR
DRIVER'S JUNCTION BOX
EXCEPT PLUG-IN HYBRID
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FORWARD COLLISION WARNING IND (FCW)
FUSE 21
FUSE 5
FUSE 7
GAUGE CONTROL MODULE
GRY WIRE
HEAD-UP WARNING UNIT (BEHIND INSTRUMENT CLUSTER)
HOT AT ALL TIMES
LANE DEPARTURE WARNING IND (LDW)
LDW OFF SWITCH
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PLUG-IN HYBRID
PPL
PPL PPL
RED WIRE
RELAY ENERGIZED
UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
W/ ACC
W/ HOMELINK
WHT WIRE
YEL WIRE
