Car Wiring Diagrams for Compass circuit for Honda Accord IX (2012-2016)

AUDIO UNIT/ AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE CENTER JUNCTION BOX COMPUTER DATA LINES SYSTEM COUPE, SEDAN DRIVER'S JUNCTION BOX ELECTRICAL COMPASS UNIT (UNDER CENTER OF REAR SHELF) FUSE GRN WIRE HOT W/ ACCESSORY SUB RELAY ENERGIZED LT BLU WIRE ORG/ WIRE PPL PPL PNK WIRE RED WIRE RELAY ENERGIZED UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH)
