Wiring diagram engine performance 2.0l hybrid, hybrid system circuit, plug-in hybrid for Honda Accord IX (2012-2016)

Wiring diagram engine performance 2.0l hybrid, hybrid system circuit, plug-in hybrid (1 of 10)

Accord Honda IX (2012-2016): Wiring diagram engine performance 2.0l hybrid, hybrid system circuit, plug-in hybrid (1 of 10)

Get access

19 20 PNK WIRE AIR CONDITIONING SYSTEM COOLING FANS SYSTEM BATTERY CONDITION MONITOR MODULE (TOP RIGHT REAR OF BATTERY PACK ASSEMBLY) BLK WIRE BLU WIRE BRN WIRE CENTER JUNCTION BOX CHARGE LID ACTUATOR (LEFT END OF DASH) CHARGE LID ILLUMINATION LAMP SWITCH CHARGE LID ILLUMINATION LAMP/CHARGE INDICATOR CHARGE LID OPENER SWITCH COOLING FANS SYSTEM COOLING FANS SYSTEM PPL DRIVE'S JUNCTION BOX FUSE FUSE 18-1 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY FUSE BOX (LEFT REAR OF ENGINE COMPT) LT BLU WIRE LT GRN WIRE MICU ORG/ WIRE ORG/BLK WIRE PNK PNK WIRE PNK WIRE PPL RED WIRE RED/BLU WIRE SUPPLEMENTAL RESTRAINTS SYSTEM TAN WIRE UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH) WHT WIRE WHT/BLK WIRE YEL WIRE

Wiring diagram engine performance 2.0l hybrid, hybrid system circuit, plug-in hybrid (2 of 10)

Accord Honda IX (2012-2016): Wiring diagram engine performance 2.0l hybrid, hybrid system circuit, plug-in hybrid (2 of 10)

Get access

19 20 PNK WIRE 21 22 23 24 25 26 27 28 PPL 3 4 5 PNK WIRE BATTERY CHARGER BATTERY CONDITION MONITOR MODULE (TOP RIGHT REAR OF BATTERY PACK ASSEMBLY) BLK WIRE BLU WIRE BRN WIRE CHARGE AC CONDENSER CHARGE INLET COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE ORG/ WIRE ORG/BLK WIRE PNK WIRE PPL RED WIRE TAN WIRE TRANSMISSIONS SYSTEM WHT WIRE YEL WIRE

Wiring diagram engine performance 2.0l hybrid, hybrid system circuit, plug-in hybrid (3 of 10)

Accord Honda IX (2012-2016): Wiring diagram engine performance 2.0l hybrid, hybrid system circuit, plug-in hybrid (3 of 10)

Get access

21 22 23 24 25 26 27 28 PPL 3 4 5 PNK WIRE BATTERY CURRENT SENSOR BATTERY PACK BLK WIRE BLU WIRE BRN WIRE BYPASS CONTACTOR CELL VOLTAGE SENSOR 1 CELL VOLTAGE SENSOR 2 COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE HIGH VOLTAGE BATTERY MODULE TEMPERATURE SENSOR HIGH VOLTAGE CONTACTOR HIGH VOLTAGE SUB CONTACTOR JUNCTION BOARD (RIGHT FRONT OF BATTERY PACK ASSEMBLY) LT BLU WIRE LT GRN WIRE MAIN SWITCH ORG/ WIRE ORG/BLK WIRE ORG/WHT WIRE PNK WIRE PPL RED WIRE TAN WIRE TO CELL VOLTAGE SENSOR 3 (DIAGRAM 5 OF 10) WHT WIRE YEL WIRE

Wiring diagram engine performance 2.0l hybrid, hybrid system circuit, plug-in hybrid (4 of 10)

Accord Honda IX (2012-2016): Wiring diagram engine performance 2.0l hybrid, hybrid system circuit, plug-in hybrid (4 of 10)

Get access

BLK WIRE BLU WIRE BRN WIRE GRY WIRE LT GRN WIRE ORG/WHT WIRE PNK WIRE PPL PPL 19 20 21 22 23 24 25 26 27 RED WIRE TAN WIRE WHT WIRE YEL WIRE

Wiring diagram engine performance 2.0l hybrid, hybrid system circuit, plug-in hybrid (5 of 10)

Accord Honda IX (2012-2016): Wiring diagram engine performance 2.0l hybrid, hybrid system circuit, plug-in hybrid (5 of 10)

Get access

BATTERY PACK BLK WIRE BLU WIRE BRN WIRE CELL VOLTAGE SENSOR 3 CELL VOLTAGE SENSOR 4 COMPUTER DATA LINES SYSTEM FROM CELL VOLTAGE SENSOR 2 (DIAGRAM 3 OF 10) GRN WIRE GRY WIRE HIGH VOLTAGE BATTERY MODULE TEMPERATURE SENSOR HOT AT ALL TIMES UNDER DASH SUB FUSE BOX (LEFT END OF DASH) FUSE LT BLU WIRE LT GRN WIRE ORG/WHT WIRE PNK WIRE PPL PPL 13 14 PPL 19 20 21 22 23 24 25 26 27 RED WIRE TAN WIRE WHT WIRE YEL WIRE

Wiring diagram engine performance 2.0l hybrid, hybrid system circuit, plug-in hybrid (6 of 10)

Accord Honda IX (2012-2016): Wiring diagram engine performance 2.0l hybrid, hybrid system circuit, plug-in hybrid (6 of 10)

Get access

12 VOLT CHARGING SYSTEM INDICATOR B- CAN L CAN H B-CAN TRANSCEIVER B- BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DIMMING CIRCUIT EV INDICATOR GAUGE CONTROL MODULE GRN WIRE GRY WIRE HV INDICATOR HV SWITCH ILLUMINATION CONTROL, DIMMING CIRCUIT FOR LCD (MID) BACK LIGHT (WHITE) LT BLU WIRE ORG/WHT WIRE PCM (LEFT FRONT OF ENGINE COMPT) PNK 3 4 5 WIRE PNK WIRE POWER SUPPLY CIRCUIT/CONTROLLER AREA NETWORK CONTROLLER POWER SYSTEM INDICATOR PPL PPL 11 12 13 14 15 16 17 18 19 PPL 13 14 PPL 7 8 9 RED WIRE TAN WIRE WHT WIRE YEL WIRE

Wiring diagram engine performance 2.0l hybrid, hybrid system circuit, plug-in hybrid (7 of 10)

Accord Honda IX (2012-2016): Wiring diagram engine performance 2.0l hybrid, hybrid system circuit, plug-in hybrid (7 of 10)

Get access

BATTERY PACK BLK WIRE BLU WIRE CELL VOLTAGE SENSOR 5 CELL VOLTAGE SENSOR 6 COMPUTER DATA LINES SYSTEM GRN WIRE HIGH VOLTAGE BATTERY MODULE TEMPERATURE SENSOR LT GRN WIRE ORG/WHT WIRE PNK 3 4 5 WIRE PNK WIRE PPL PPL 11 12 13 14 15 16 17 18 19 PPL 7 8 9 RED WIRE TAN WIRE TO CELL VOLTAGE SENSOR 7 (DIAGRAM 8 OF 10) WHT WIRE YEL WIRE

Wiring diagram engine performance 2.0l hybrid, hybrid system circuit, plug-in hybrid (8 of 10)

Accord Honda IX (2012-2016): Wiring diagram engine performance 2.0l hybrid, hybrid system circuit, plug-in hybrid (8 of 10)

Get access

BATTERY PACK BLK WIRE BLU WIRE CELL VOLTAGE SENSOR 7 CELL VOLTAGE SENSOR 8 COMPUTER DATA LINES SYSTEM FROM CELL VOLTAGE SENSOR 6 (DIAGRAM 7 OF 10) FUSE BOX (LEFT REAR OF ENGINE COMPT) GRN WIRE HIGH VOLTAGE BATTERY MODULE TEMPERATURE SENSOR HOT AT ALL TIMES LT GRN WIRE ORG/WHT WIRE PNK WIRE PPL RED WIRE RELAY RELAY CIRCUIT BOARD TAN WIRE UNDER-HOOD FUSE/RELAY WHT WIRE YEL WIRE

Wiring diagram engine performance 2.0l hybrid, hybrid system circuit, plug-in hybrid (9 of 10)

Accord Honda IX (2012-2016): Wiring diagram engine performance 2.0l hybrid, hybrid system circuit, plug-in hybrid (9 of 10)

Get access

AIR CONDITIONING SYSTEM BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM GATE DRIVER BOARD GRN WIRE GRY WIRE IPIN LT BLU WIRE LT GRN WIRE MOTOR CONTROL MODULE MPI MODULE ORG/ WIRE PHASE GENERATOR CURRENT SENSOR PHASE MOTOR CURRENT SENSOR PNK 15 24 WIRE PNK 19 32 WIRE PPL 16 2 PPL 3 25 4 PPL 9 31 8 REACTOR TEMPERATURE SENSOR RED WIRE TAN WIRE WHT WIRE YEL WIRE

Wiring diagram engine performance 2.0l hybrid, hybrid system circuit, plug-in hybrid (10 of 10)

Accord Honda IX (2012-2016): Wiring diagram engine performance 2.0l hybrid, hybrid system circuit, plug-in hybrid (10 of 10)

Get access

BLK WIRE BLU WIRE BRN WIRE GENERATOR MOTOR GENERATOR MOTOR ROTOR POSITION SENSOR GENERATOR MOTOR TEMPERATURE SENSOR GRN WIRE LT BLU WIRE LT GRN WIRE MOTOR ASSEMBLY) ORG/ WIRE PNK 17 18 WIRE PNK 24 25 WIRE PNK WIRE PPL PPL 14 15 16 PPL 21 22 23 PPL 3 4 RED WIRE TRACTION MOTOR TRACTION MOTOR ROTOR POSITION SENSOR TRACTION MOTOR TEMPERATURE SENSOR WHT WIRE YEL WIRE
