Computer data lines circuit, except hybrid for Honda Accord IX (2012-2016)

Computer data lines circuit, except hybrid (1 of 4)

Accord Honda IX (2012-2016): Computer data lines circuit, except hybrid (1 of 4)

Get access

16 17 PNK WIRE AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE CENTER JUNCTION BOX DLC (UNDER LEFT SIDE OF DASH) EXCEPT SPORT FRONT PASSENGER'S WEIGHT SENSOR UNIT GRY WIRE HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY FUSE BOX (LEFT SIDE OF ENGINE COMPT) HVAC CONTROL UNIT/ CLIMATE CONTROL UNIT IMMOBILIZER KEYLESS CONTROL UNIT (SPORT) LT BLU WIRE MICU OPTIONAL CONNECTOR PNK 14 15 WIRE PNK PNK WIRE PNK WIRE POWER WINDOW MASTER SWITCH (IF EQUIPPED) RED WIRE SPORT UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH) WHT WIRE YEL WIRE

Computer data lines circuit, except hybrid (2 of 4)

Accord Honda IX (2012-2016): Computer data lines circuit, except hybrid (2 of 4)

Get access

10 11 PNK WIRE 16 17 PNK WIRE 25 26 27 28 29 PNK PNK WIRE BLU WIRE EXCEPT SPORT GAUGE CONTROL MODULE GRY WIRE LT BLU WIRE PNK 14 15 WIRE PNK 23 24 WIRE PNK WIRE RED WIRE SEDAN SPORT SUNLIGHT SENSOR (TOP MIDDLE OF DASH) WHT WIRE YEL WIRE

Computer data lines circuit, except hybrid (3 of 4)

Accord Honda IX (2012-2016): Computer data lines circuit, except hybrid (3 of 4)

Get access

10 11 PNK WIRE 15 16 17 18 19 PNK PNK WIRE 2.4L 25 26 27 28 29 PNK PNK WIRE 3.5L ANC/ ACTIVE SOUND CONTROL UNIT (CENTER OF DASH) BLU WIRE CENTER JUNCTION BOX GRY WIRE LT BLU WIRE PNK 13 14 WIRE PNK 23 24 WIRE PNK WIRE RED WIRE WHT WIRE YEL WIRE

Computer data lines circuit, except hybrid (4 of 4)

Accord Honda IX (2012-2016): Computer data lines circuit, except hybrid (4 of 4)

Get access

15 16 17 18 19 PNK PNK WIRE BLU WIRE DRIVER'S JUNCTION BOX EXCEPT SPORT GRY WIRE KEYLESS ACCESS CONTROL UNIT (EXCEPT SPORT) (LEFT SIDE OF DASH) LT BLU WIRE PNK 13 14 WIRE PNK PNK WIRE PNK WIRE POWER SEAT CONTROL UNIT (IF EQUIPPED) (UNDER DRIVER'S SEAT) RED WIRE SPORT SRS UNIT (UNDER FRONT OF CENTER CONSOLE) WHT WIRE YEL WIRE
