Honda Accord IX (2012-2016) window master switch Wiring diagram
This page shows the only wiring diagram for the component.window master switch, which is found in the car Honda Accord IX (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram window master switch (1 of 1)
BLK WIRE
BRN WIRE
CVT
CVT DRIVEN PULLEY PRESSURE CONTROL SOLENOID VALVE
DATA LINK CONNECTOR (DLC)
DRIVER SEAT BELT BUCKLE SWITCH
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/ KEY CYLINDER SWITCH
DRIVER'S DRIVER'S SEAT HEATER SEAT RELAY HEATER (HIGH)
DRIVER'S POWER LUMBAR SUPPORT SWITCH
DRIVER'S SEAT HEATER RELAY (LOW)
DRIVER'S SEAT POSITION SENSOR
DRIVER'S VANITY MIRROR LIGHT
EXCEPT SPORT
FCW/LDW CAMERA UNIT
FRONT INDIVIDUAL MAP LIGHTS
FRONT PASSENGER'S FRONT SEAT HEATER PASSENGER'S RELAY (HIGH) SEAT HEATER
FRONT PASSENGER'S SEAT HEATER RELAY (LOW)
GRN WIRE
GRY WIRE
LT BLU WIRE
MICU
PASSENGER'S VANITY MIRROR LIGHT
POWER MIRROR SWITCH
POWER SEAT CONTROL UNIT
SEDAN
SPORT
SRS UNIT
W/ SEAT HEATER
WHT WIRE
WINDOW MASTER SWITCH
YEL WIRE
Go to component -> Ground distribution circuit, except hybrid (3 of 4) -> WINDOW MASTER SWITCH
