Honda Accord IX (2012-2016) throttle open sensor Wiring diagram
This page shows the only wiring diagram for the component.throttle open sensor, which is found in the car Honda Accord IX (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram throttle open sensor (1 of 1)
APP APP SENSOR A SENSOR B APP SENSOR (ON ACCELERATOR PEDAL SUPPORT)
BLK WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH (ON BRAKE PEDAL SUPPORT)
BRN WIRE
COMPUTER DATA LINES SYSTEM
ETCS CONTROL RELAY
EXCEPT PLUG-IN HYBRID PLUG-IN HYBRID
FUSE 10
FUSE 13
FUSE 4
FUSE 5
FUSE 7
FUSE 8
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PCM (LEFT FRONT OF ENGINE COMPT)
PGM-FI MAIN RELAY 1
PNK WIRE
PPL
RED WIRE
RELAY ENERGIZED
THROTTLE ACTUATOR THROTTLE BODY (REAR OF INTAKE MANIFOLD)
THROTTLE OPEN SENSOR
TRANSMISSION RANGE SWITCH (TOP OF TRANSMISSION)
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Adaptive cruise control circuit, hybrid (1 of 3) -> THROTTLE OPEN SENSOR
