Honda Accord IX (2012-2016) red Wiring diagrams

This page contains all the electrical diagrams for the component. red, in which he is found in the car Honda Accord IX (2012-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram red (201 of 253)

Wiring diagram red for Honda Accord IX (2012-2016) (201 of 253)

Get lifetime access to Honda Accord IX (2012-2016)

AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BRN WIRE CABLE REEL (IN STEERING COLUMN) GRN WIRE GRY WIRE HANG-UP BACK SWITCH HFL/HFL- NAVIGATION VOICE CONTROL SWITCH LT BLU WIRE LT GRN WIRE MULTI INFORMATION DISPLAY UNIT NCA WIRE PICK-UP SWITCH PNK 19 20 21 22 23 24 25 26 27 28 29 WIRE PNK WIRE PPL PPL 14 15 16 17 18 PPL 4 5 REARVIEW CAMERA (CENTER REAR OF LUGGAGE COMPT LID) RED WIRE RIGHT POWER MIRROR ROOF ANTENNA SUB AMPLIFIER TALK SWITCH WHT WIRE YEL WIRE

Go to component -> Base radio circuit, hybrid (4 of 4) -> RED WIRE

Wiring diagram red (202 of 253)

Wiring diagram red for Honda Accord IX (2012-2016) (202 of 253)

Get lifetime access to Honda Accord IX (2012-2016)

AUDIO REMOTE SWITCH AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE CABLE REEL (IN STEERING COLUMN) CENTER JUNCTION BOX CH+ SWITCH CH- SWITCH COMPUTER DATA LINES SYSTEM DISP SWITCH FUSE 37 FUSE FUSE (LEFT SIDE OF ENGINE COMPT) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACCESSORY SUB RELAY ENERGIZED LT BLU WIRE LT GRN WIRE MICU NCA WIRE PNK 10 11 WIRE PNK 6 7 WIRE PNK PNK WIRE PNK WIRE PPL PPL 12 13 PPL PPL 2 3 REAR ANC/ACTIVE SOUND CONTROL MICROPHONE (UNDER MIDDLE OF REAR SHELF) RED WIRE SOURCE SWITCH UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH) UNDER-HOOD FUSE/RELAY BOX USB PORT VOLUME DOWN SWITCH VOLUME UP SWITCH WHT WIRE YEL WIRE

Go to component -> Premium radio circuit, except hybrid with navigation (1 of 5) -> RED WIRE

Wiring diagram red (203 of 253)

Wiring diagram red for Honda Accord IX (2012-2016) (203 of 253)

Get lifetime access to Honda Accord IX (2012-2016)

1 2 PPL ANC/ACTIVE SOUND CONTROL UNIT (CENTER OF DASH) AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE CENTER JUNCTION BOX COMPUTER DATA LINES SYSTEM DRIVER'S JUNCTION BOX GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE NAVIGATION SWITCH PANEL ORG/ WIRE PARKING BRAKE SWITCH PCM (2.4L: LEFT SIDE OF ENGINE COMPT) PNK 10 11 WIRE PNK 13 14 WIRE PNK 15 16 WIRE PNK 6 7 WIRE PNK WIRE PPL PPL 12 13 PPL PPL 2 3 RED WIRE STEREO AMPLIFIER (RIGHT END OF DASH) WHT WIRE YEL WIRE

Go to component -> Premium radio circuit, except hybrid with navigation (2 of 5) -> RED WIRE

Wiring diagram red (204 of 253)

Wiring diagram red for Honda Accord IX (2012-2016) (204 of 253)

Get lifetime access to Honda Accord IX (2012-2016)

1 2 PPL ANTENNA AMPLIFIER AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE COMBINATION LIGHT SWITCH DRIVER'S DOOR SPEAKER FRONT HFL- NAVIGATION- ANC/ACTIVE SOUND CONTROL MICROPHONE FRONT PASSENGER'S DOOR SPEAKER FUSE FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT REAR SPEAKER LEFT TWEETER LT BLU WIRE LT GRN WIRE NCA WIRE ORG/ WIRE PNK 13 14 WIRE PNK 15 16 WIRE PNK WIRE PPL PPL 1 2 RDS/TMC ANTENNA MODULE RED WIRE RIGHT REAR SPEAKER RIGHT TWEETER SUBWOOFER UNDER-DASH SUB FUSE BOX (LEFT END OF DASH) WHT WIRE YEL WIRE

Go to component -> Premium radio circuit, except hybrid with navigation (3 of 5) -> RED WIRE

Wiring diagram red (205 of 253)

Wiring diagram red for Honda Accord IX (2012-2016) (205 of 253)

Get lifetime access to Honda Accord IX (2012-2016)

AM/FM ANTENNA AMPLIFIER AMP AUDIO UNIT/AUDIO NAVIGATION UNIT AUXILIARY JACK ASSEMBLY BLK WIRE BRN WIRE GRN WIRE GRY WIRE LANE WATCH CAMERA LT BLU WIRE NCA WIRE PNK PPL WIRE PNK WIRE PPL PPL 1 2 REARVIEW CAMERA (CENTER REAR OF LUGGAGE COMPT LID) RED WIRE TUNER UNIT WHT WIRE XM ANTENNA YEL WIRE

Go to component -> Premium radio circuit, except hybrid with navigation (4 of 5) -> RED WIRE

Wiring diagram red (206 of 253)

Wiring diagram red for Honda Accord IX (2012-2016) (206 of 253)

Get lifetime access to Honda Accord IX (2012-2016)

AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE GRN WIRE GRY WIRE HANDSFREELINK CONTROL UNIT (LOWER CENTER OF DASH) LT BLU WIRE LT GRN WIRE MULTI INFORMATION DISPLAY UNIT NCA WIRE PNK PPL WIRE PNK WIRE PPL RED WIRE WHT WIRE YEL WIRE

Go to component -> Premium radio circuit, except hybrid with navigation (5 of 5) -> RED WIRE

Wiring diagram red (207 of 253)

Wiring diagram red for Honda Accord IX (2012-2016) (207 of 253)

Get lifetime access to Honda Accord IX (2012-2016)

AUDIO REMOTE SWITCH AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE CABLE REEL (IN STEERING COLUMN) CENTER JUNCTION BOX CH+ SWITCH COMPUTER DATA LINES SYSTEM DISP SWITCH FUSE FUSE 22 FUSE 21 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACCESSORY SUB RELAY ENERGIZED LT BLU WIRE LT GRN WIRE NCA WIRE PNK 4 5 WIRE PNK 8 9 WIRE PNK PNK WIRE PNK WIRE PPL PPL 10 11 REAR ANC/ACTIVE SOUND CONTROL MICROPHONE (UNDER MIDDLE OF REAR SHELF) RED WIRE SOURCE SWITCH UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH) UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT) USB PORT VOLUME DOWN SWITCH VOLUME UP SWITCH WHT WIRE YEL WIRE

Go to component -> Premium radio circuit, except hybrid without navigation (1 of 5) -> RED WIRE

Wiring diagram red (208 of 253)

Wiring diagram red for Honda Accord IX (2012-2016) (208 of 253)

Get lifetime access to Honda Accord IX (2012-2016)

ANC/ACTIVE SOUND CONTROL UNIT (CENTER OF DASH) BLK WIRE BLU WIRE BRN WIRE CENTER JUNCTION BOX COMPUTER DATA LINES SYSTEM FUSE GRN WIRE GRY WIRE HOT W/ LT BLU WIRE LT GRN WIRE MICU ORG/ WIRE PNK 10 11 WIRE PNK 12 13 WIRE PNK 4 5 WIRE PNK 8 9 WIRE PNK WIRE PPL PPL 10 11 RED WIRE STEREO AMPLIFIER (RIGHT END OF DASH) UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH) WHT WIRE YEL WIRE

Go to component -> Premium radio circuit, except hybrid without navigation (2 of 5) -> RED WIRE

Wiring diagram red (209 of 253)

Wiring diagram red for Honda Accord IX (2012-2016) (209 of 253)

Get lifetime access to Honda Accord IX (2012-2016)

AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE DRIVER'S DOOR SPEAKER FRONT PASSENGER'S DOOR SPEAKER FUSE 4 FUSE 1 OF DASH) GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT REAR SPEAKER LEFT TWEETER LT BLU WIRE LT GRN WIRE NAVIGATION SYSTEM ORG/ WIRE PNK 10 11 WIRE PNK 12 13 WIRE PNK WIRE PPL PPL 1 2 RED WIRE RIGHT REAR SPEAKER RIGHT TWEETER SUBWOOFER UNDER-DASH SUB FUSE BOX (LEFT END WHT WIRE YEL WIRE

Go to component -> Premium radio circuit, except hybrid without navigation (3 of 5) -> RED WIRE

Wiring diagram red (210 of 253)

Wiring diagram red for Honda Accord IX (2012-2016) (210 of 253)

Get lifetime access to Honda Accord IX (2012-2016)

AM/FM ANTENNA AMPLIFIER AMP AUDIO UNIT/AUDIO NAVIGATION UNIT AUXILIARY JACK ASSEMBLY BLK WIRE BRN WIRE FRONT HFL-ANC/ACTIVE SOUND CONTROL MICROPHONE GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE NAVIGATION SYSTEM NCA WIRE ORG/ WIRE PNK 14 15 WIRE PNK PPL WIRE PNK WIRE PPL PPL 1 2 RED WIRE TUNER UNIT WHT WIRE XM ANTENNA YEL WIRE

Go to component -> Premium radio circuit, except hybrid without navigation (4 of 5) -> RED WIRE
