Honda Accord IX (2012-2016) rear up-down switch Wiring diagram
This page shows the only wiring diagram for the component.rear up-down switch, which is found in the car Honda Accord IX (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear up-down switch (1 of 1)
B-CAN TRANSCEIVER B-CAN H B-CAN L
BACK- WARD
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM PNK WIRE
COUPE
DOWN
DRIVER'S JUNCTION BOX
DRIVER'S SEAT DRIVER'S SEAT FRONT UP-DOWN REAR UP-DOWN MOTOR MOTOR
DRIVER'S SEAT RECLINE MOTOR
DRIVER'S SEAT SLIDE MOTOR
FOR- WARD
FRONT UP-DOWN SWITCH
FUSE 15
FUSE 36
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH)
KEYLESS ACCESS CONTROL UNIT
LIMIT SWITCH
LT BLU WIRE
LT GRN WIRE
MAIN CIRCUIT
ORG/ WIRE
PARKING BRAKE SWITCH
PNK WIRE
POWER SEAT CONTROL UNIT (UNDER DRIVER'S SEAT)
PPL
PPL PNK WIRE
PPL PPL
REAR UP-DOWN SWITCH
RECLINE SWITCH
RED WIRE
RELAY ENERGIZED
SEDAN
SENSOR
SLIDE SWITCH
WHT WIRE
YEL WIRE
Go to component -> Memory systems circuit, except hybrid (1 of 2) -> REAR UP-DOWN SWITCH
